Ashley Red Multi - Clay Facing Brick

Name: Ashley Red Multi - Clay Facing Brick
Brand: Wienerberger Ltd
SKU: qJbXiN6vYYQnLtREoFVZZ9

Verified by manufacturer 22 days ago

Wienerberger Ltd

Waterstruck solid brick in red multi colour with waterstruck appearance.

Jump to:

Request BIM

+44 (0)161 4918200 Website

Application

Suitable for external use.

Description

Made using a similar process to stock bricks but the bricks are released from the moulds using water. This process, along with a wetter clay mix, gives waterstruck bricks a distinctive texture.

Features and benefits:

Waterstruck appearance.
Red multi colour.
Indent at the top of the brick known as a 'frog'.
Sized inline with BS EN 771-1.

General information

Color	Other Red Brown Manufacturer guidance Grey Multi
Finish	Waterstruck
Material	Clay
Shape	Rectangle
Length	215 mm
Width	102.5 mm
Height	65 mm

Uniclass	Pr_20_93_52_15 Clay bricksPrimary
CAWS	F10/5 Facing brickwork F10/110 Clay facing brickwork

SKU Code	11139927

Specification data - Clay bricks

Classification data
Standard	To BS EN 771-1.
Brick description	Facing brick.
Appearance	Waterstruck.
Work size (length x width x height)	215 x 102.5 x 65 mm.
Tolerances	-
Mean value	T2.
Range	R1.
Compressive strength	-
Mean compressive strength (minimum)	≥20 N/mm².
Category	I.
Durability designation	F2.
Density	-
Gross dry	1750 kg/m³.
Tolerance	D1.
Water absorption	≤12%. Guidance for specification option: Percentage of water overall absorption.
Configuration	Frogged.
Thermal conductivity	P=50% 0.53 W/m⋅K. Guidance for specification option: 10,dry,unit value (EN 1745 tabulated: S1).
Water vapour permeability	- Manufacturer guidance Refer to EN 1745.
Bond strength	- Manufacturer guidance Refer to EN 1052-3.
Reaction to fire	Class A1 to BS EN 13501-1.
Active soluble salts	S2.
Dry weight	2.7 kg. Guidance for specification option: Individual Dry Brick Weight (kg).
