ISO-BLOCO 600

Verified by manufacturer 4 months ago

ISO-BLOCO 600 Colour Edition

ISO-Chemie GmbH Variant:
Third party certifications:
  • BBA Agrément Certificate

    BBA Agrément Certificate

    Certificate type

Joint sealing tape.

Jump to:
+44 (0)1207 566867 Website

Application

Generally used for sealing construction joints in areas such as between prefabricated concrete, skylights, cladding panels, curtain walling and perimeter seal for windows and doors.

Description

PUR foam sealing tape impregnated with a fire resistant polymeric dispersion. It is specially designed for joints in buildings up to 100 high, in accordance with DIN 18055. In addition to providing protection against driving rain to a minimum of 600 Pa, the vapour permeable joint sealing tape also possesses outstanding thermal and acoustic characteristics.


Features and benefits:

  • Complies with DIN 18542 BG 1/ BG R and DIN 18055.
  • Provides reliability through a wide joint application range.
  • Seals against wind, dust, driving rain.
  • Vapour diffusion permeable.
  • Good adhesive properties to aid application.
  • Permanently elastic with long term life expectancy.
  • Can be painted over with standard emulsion paints.
  • Compatible with all known standard building materials.
  • Application in all construction areas and building types is possible.
  • Also available pre-painted as ISO-BLOCO 600 Colour Edition (BG1).
  • Externally certified by ift Rosenheim: For driving rain and air permeability (a-value).
  • Complies with EnEV requirements and the recommendations of the RAL 'Installation guide'.
  • Ten years externally supervised outdoor weathering.
  • Ten-year function warranty.

General information

Color

Material

Polyurethane

Guidance for specification option:

PUR foam.

Warranty description

Ten year

Uniclass

Pr_35_90_87_71 Resin-impregnated precompressed foam sealing stripsPrimary

CAWS

E40/545 Compressible sealing strip system

F30/610 Movement joints with sealant

F30/615 Movement joints without sealant

F30/78 Fire-resisting movement joints without sealant

H11/110 Curtain walling

H13/115 Structural glass assembly

H42/661 Sealant joints

L10/75 Sealant joints

L10/810 Sealant joints

L20/80 Sealant joints

L20/820 Sealant joints

Product range

Pre-compressed Joint Sealing Tapes

Specification data - Resin-impregnated precompressed foam sealing strips

Materials

-

Foam

Polyurethane.

Type

ISO-BLOCO 600 Colour Edition.

Joint width

Guidance for specification option:

Insert requirement, available for widths up to 42 mm.

Colour

Blue.

Guidance for specification option:

For Colour Edition only.

Brick red.

Guidance for specification option:

For Colour Edition only.

Brown.

Guidance for specification option:

For Colour Edition only.

Green.

Guidance for specification option:

For Colour Edition only.

Sand.

Guidance for specification option:

For Colour Edition only.

Show more

Third party certifications

BBA Agrément Certificate

08/4555. Bloco One
