i.Care 710 Doc M C/C Comfort Height WC Pan Rimless
Verified by manufacturer 4 months ago
1903.C.L.00.BW - I.Care DOCM C/C Cistern With WRAS Approved
1903.C.L.00.BW - I.Care DOCM C/C Cistern With WRAS Approved
Rimless WC pan and cistern.
Application
Suitable for close-coupled WC-suites.
Description
Rimless WC pan, cistern with WRAS approved push button fitting or lever handle.
General information
Color | White |
Material | Ceramic |
Shape | Other |
Length | 710 mm Guidance for specification option: WC Pan. 195 mm Guidance for specification option: Cistern. |
Width | 365 mm Guidance for specification option: WC Pan. 460 mm Guidance for specification option: Cistern. |
Height | 470 mm Guidance for specification option: WC Pan. 367 mm Guidance for specification option: Cistern. |
Uniclass | |
CAWS | N13/311 Unisex accessible WC equipment packages (Document M) N13/12 Unisex accessible WC equipment packages (Document M) N13/302 WCs and flushing valves N13/300 WCs and cisterns N13/10 WC pans and flushing arrangements |
Specification data - WC suites
Standards | |
Cisterns | To BS EN 997, Class 2. |
Pans | To BS EN 997, Class 2. |
Approvals | Water Regulations Approval Scheme (WRAS)-approved. |
Form | Back-to-wall WC pan and cistern. |
Connecting dimensions | To BS EN 33. |
Materials | |
Body | Ceramic. |
Finish and colour | Euro white. |
Sizes | |
Cistern capacity | 6 L. |
Pan height | 470 mm. |
Integral accessories | 1910.BW - I.Care Slow Close Seat & Cover (Bright White). |
Projection | 710 mm. |
Width | 460 mm. |
Automation | Manual, handle. |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
Literature
I.Care DOCM C/C WC Pan New Rimless
I.Care DOCM C/C WC Pan Rimless
