Hardie® Architectural Panel Cladding - Brushed Concrete 8mm

Name: Hardie® Architectural Panel Cladding - Brushed Concrete 8mm
Brand: James Hardie Building Products Ltd
SKU: gX1uLV7TF2CFhQj762tMNK

Verified by manufacturer over a year ago

James Hardie Building Products Ltd

Third party certifications:

BBA Agrément Certificate
Certificate type
EPD
Certificate type

Hardie® Architectural Panel cladding is an 8 mm thick, large format sheet available in six core colours.

Jump to:

+44(0)1213113480 Website

Application

Purposely designed as an external cladding for residential and commercial buildings in both new build and renovation. Hardie® Architectural Panel cladding can be used in a ventilated construction fixed to timber frame, steel frame or masonry walls using corrosion resistant screws or rivets.

Can be installed horizontally and vertically, with or without insulation.

Description

Hardie® Architectural Panel cladding is a robust, heavy-duty fibre cement cladding product in a brushed concrete effect finish, providing diverse design options.

Hardie® Architectural Panel cladding is available in six core colours, each offering ColorPlus® Technology for projects that call for specific colours. The 15 year limited warranty guarantees that all Hardie® Panel cladding installations will maintain their fresh appearance year after year.

Installation requires minimum pre-drilling and the panel sheets can be easily cut to size on site. Hardie® Panel offers a simple, durable and economical solution and is particularly suitable for large new or renovation projects.

Features and benefits:

Cost effective, functional large sheet cladding offering great design flexibility.
Fire resistant and non combustible A2-s1, d0 fire rated.
Engineered for climate and offering year round install for ease.
Low maintenance.
Made to last.
The best of both strength and usability.
Superior dimensional stability.

Smooth Sand version also available, which can be specified separately.

Standards:

Construction material class as per EN 13501-1: non-flammable A2-s1, d0.
BBA certified 05/4248.
DIBt approval = abZ Z-31.4-193.

General information

Color	White Grey Black Other
Finish	Brushed Guidance for specification option: Brushed concrete effect.
Material	Cement Guidance for specification option: Portland cement, sand, cellulose fibres, water and selected additives.
Shape	Rectangle
Length	3048 mm
Width	1220 mm
Height	8 mm
Warranty description	15 year Guidance for specification option: Covering paint and labour, protecting against peeling, cracking, and chipping.

Uniclass	Pr_25_71_11_31 Fibre-reinforced cement weatherboardsPrimary
CAWS	H20/10 Sheet cladding H20/150 Sheet cladding (attached to metal support systems) H20/155 Sheet cladding (attached to timber battens) H30/120 Fibre cement H30/110 Fibre cement H92/120 Rainscreen cladding

Specification data - Fibre-reinforced cement weatherboards

Standard	To BS EN 12467.
Fire rating	To EN 13501-1, A2-s1, d0. Guidance for specification option: Non-combustible.
Edges	Square.
Finished size	3048 x 1220 mm.
Thickness	8 mm.
Surface texture	Brushed Concrete.
Colour	Arctic White. Light Mist. Cobblestone. Grey Slate. Anthracite Grey. Midnight Black.

Density	1300 kg/m³.
Panel weight	11.2 kg/m².
ThermalConductivity	0.23 W/m⋅K.
Thermal resistance	0.024 m²K/W.

Sustainability data

Contains Red List materials	No
Country of material origin	United States
Country of product manufacture	United States
Embodied carbon A1-A3 (production stage) as defined in BS EN 15804	5.32 kg CO₂ eq/m²
Recycled content As defined in clause 7.8 of BS EN ISO 14021	0 %
