Freestanding Emergency Body Drench Shower with Eye/face Shower and Bowl Modular

Name: Freestanding Emergency Body Drench Shower with Eye/face Shower and Bowl Modular
Brand: BROEN-LAB
SKU: tojUXvbHfd855p1L3GKJKR

Verified by manufacturer 4 months ago

Third party certifications:

Freestanding emergency shower and eye shower/ face wash designed in accordance with BS EN 15154-1 & -2 and ANSI Z 358.1.

Jump to:

Application

For use where employees are at risk of direct contact with harmful substances. For use in pharma and industrial establishments and hospitals.

Freestanding emergency shower and eye shower/ face wash designed in accordance with BS EN 15154-1 & -2 and ANZI Z 358.1.

Features and benefits:

Flow rate and spray pattern in accordance with EN 15154-1.
Self-draining shower head.
Sign according to ISO 3864-1.
Illuminating 3D sign to be attached on pull rod, for easy and clear identification of emergency station.
Instruction and test sign to be wall mounted.
Plug and play assembly.
Anti-limescale design and material.
Disability-friendly and/ or anti-corrosion variants available: consult manufacturer for details.
Eye wash with built-in FLOWFIX for regulation of water flow (14 L/min).
Stainless steel bowl with integrated outlet.

Installation:

Shower must have two G1" inlets.
Eye shower must have drainage built into the emergency shower.
If possible and based on local regulations, insure thermostatic mixing valve for combi shower in installation, designed for delivering tepid water (20–25°C) with fail-safe on hot side i.e. 17512009.

Certificates:

Uniclass	Pr_40_20_27_75 Safety showersPrimary
CAWS	N13/375 Shower units N13/41 Shower heads N13/40 Shower units

Accessories	Instructions, service signs and mounting kit included.

Capacity	Single user.
Water supply	Shower/ spray tap. Guidance for specification option: Minimum operating pressure: 1.5 bar.
Operation	Manual - lever via pull rod.
Body	AISI 304 stainless steel.
Finish and colour	Polyester powder coated, signal red.
Weight	17 kg (approx).
