FD120 Fire Rated Doorsets

Name: FD120 Fire Rated Doorsets
Brand: Principal Doorsets Ltd
SKU: iCUmGVtiZ7Ds8caehcY1AH

Verified by manufacturer 4 months ago

Halspan Prima Plus FD120 62mm

Principal Doorsets Ltd

A range of FD120 fire rated doorsets.

Jump to:

+44 (0)1237 439152 Website

Application

Suitable for healthcare, education, commercial, leisure and high-end residential applications.

Description

A range of FD120 fire-rated doorsets. A range of door blanks are available including Mineral Core and Halspan options.

Features and benefits:

All doorsets can be tailored to suit each bespoke project.
Materials are supplied from a single source.
No site adjustments are necessary as tolerances and clearance gaps are pre-set and "proved" in the factory.
Doors can be supplied with hinges fixed to doors, allowing for easy door removal for safe storage.
The risk of damage is reduced as doorsets can be fitted later in the contract.
Costly site labour is reduced - health and safety controls over using woodworking tools on site are removed.

General information

Color	Brown Other
Finish	Veneered Painted Stained Primed Laminated
Material	Wood
Shape	Rectangle
Length	Bespoke
Width	Bespoke
Height	Bespoke

Uniclass	Pr_30_59_24_97 Wood doorsetsPrimary
CAWS	L20/410 Wood doorsets L20/55 Doorsets

Specification data - Wood doorsets

Standard	Internal fire-rated doorset third-party-certified.
Configuration	Single-leaf, single-action. Double-leaf, single-action.
Performance	-
Fire resistance	-
Integrity	120 minutes.
Acoustic performance	Manufacturer's standard.
Frame	-
Material	Hardwood.
Perimeter seals or inserts	Fire seal. Fire and smoke seal.
Finish	Polished. Primed ready for site finish. Full paint finish. Factory stain.
External	Guidance for specification option: Insert requirements or omit.
Internal	Guidance for specification option: Insert requirements or omit.
Door leaf	-
Thickness	62 mm.
Core	Three-layer particleboard with mineral facing.
Facings	None. Veneer. High pressure laminate. PVC. Metal facings.
Species	Not applicable. Ash. Ash burr. Ash olive. Beech steam. Beech white. Birch. Cherry American. Cherry European. Chestnut crown. Chestnut quartered. Ebony. Elm European. Elm red. Eucalyptus. Iroko. Jatoba. Koto. Mahogany African. Mahogany figured. Makore. Maple burr. Maple birds eye. Maple crown. Maple figured. Movingui. Oak American crown. Oak burr. Oak European crown. Oak European rift. Oak pippy. Oak red. Swiss pear. Sycamore European. Sycamore figured. Sycamore weathered crown. Sycamore weathered quartered. Teak. Tropical olive. Tulip wood. Utile. Walnut African. Walnut American. Walnut American burr. Walnut European. Walnut satin. Wenge. Yew. Zebrano. Manufacturer guidance Veneer methods - Popular lay-ons include book matched, slip matched, centre jointed and centred feature and quartered. Consult manufacturer for details.
Lippings	3 mm lipping.
Finish	Veneer - Polished. Guidance for specification option: As standard, 25% gloss levels. Veneer - Polished, with added Hygienilac. Veneer - Unfinished. Full paint finish. Guidance for specification option: Doorsets supplied fully painted to match your colour schemes. Standard gloss level 10%. Insert requirements. Factory stain. Fumed. Primed. High pressure laminate. Guidance for specification option: Decorative laminates are available to give increased impact resistance. Laminate finishes have a surface colour and slightly textured finish. Consult manufacturer for details and insert requirements. PVC. Guidance for specification option: PVC facings are available to give increased impact resistance. PVC has a through colour and smooth finish. Consult manufacturer for details and insert requirements.
Colour	-
External	Guidance for specification option: Insert requirements or omit.
Internal	Guidance for specification option: Insert requirements or omit.
Glazing	-
Type	-
Hardware	Guidance for specification option: Principal Doorsets have a full range of ironmongery brands. Consult manufacturer and insert requirements or refer to a schedule.
Architraves	-
Material	Not required. Hardwood. Softwood. MDF.
Finish	Polished. Guidance for specification option: Hardwood architraves. Primed ready for site finish. Guidance for specification option: Softwood or MDF architraves. Full paint finish. Guidance for specification option: Softwood or MDF architraves. Factory stain. Guidance for specification option: Softwood or MDF architraves.
Colour	-
External	Guidance for specification option: Insert requirements or omit.
Internal	Guidance for specification option: Insert requirements or omit.
Accessories	None. Door edge protection. Kickplates.

Certification	FSC certified.

Sustainability data

Contains Red List materials	No
Country of material origin	Europe
Country of product manufacture	Europe
Material	Wood
Recyclability	100%
Expected Life	20 year
