FBC Eco Permeable BS 7533 part 101, Type 35 Bedding Mortar

Name: FBC Eco Permeable BS 7533 part 101, Type 35 Bedding Mortar
Brand: Larsen Building Products
SKU: nJDYmwu66L2ZJ21UgHRsd1

Verified by manufacturer 7 days ago

Larsen Building Products

Product certifications:

ISO 9001 Quality Management
Certificate type
Renewable Obligation Certificate (ROC)
Certificate type

Fine bedding concrete specifically designed to meet or exceed the requirements of BS 7533 part 101, type 35, table 9.

Jump to:

+44 (0)28 9077 4000 Website

Application

Suitable for pavements constructed with clay, concrete or natural stone paving units.

BS 7533 / BS7533 part 101 compliant.

Description

Larsen Streetscape FBC permeable ECO is a fine bedding concrete specifically designed to meet or exceed the requirements of BS 7533 part 101. Manufactured from a controlled blend of aggregate, cement and GGBS it only requires the addition of water to produce a fully BS 7533 part 101 (code of practice for the structural design of pavements using modular paving units) compliant bedding mortar for the laying course.

Features and benefits:

BS 7533 part 101 compliant.
Permeable.
Eco - reduced carbon.
Available in 1.2 tonne bulk bags.

General information

Color	Grey
Finish	Textured
Material	Cementitious
Shape	Formless
Length	Bespoke
Width	Bespoke
Height	Bespoke
Warranty description	40 year

Uniclass	Pr_20_31_16_29 Fine bedding concretesPrimary
CAWS	M40/32 Mortar bedding M40/570 Mortar bedding

Specification data - Fine bedding concretes

Standard/ performance requirements	BS 7533-4:2006, BS 7533-7:2010, BS 7533-10: 2010, BS 7533-12:2006.
Consistency	Pre-blended dry powder.

Aggregate	6 mm. Manufacturer guidance Maximum size.
WaterContent	7.2–8%.
Materials	Cementitious.
Permeability	≥5 x 10^-5 m/s.
Typical compressive strength	>35 MPa.
Mortar designation	To BS 7533-7:2010 C.2.1 and table C4 Type A and Type B compliant. To BS 7533-7: 2010 C.2.1 and table C4 Type B compliant.
Working temperature	2ºC–30ºC.
Working time	60 minutes. Manufacturer guidance Approximate time.
Adhesion strength	1 N/mm² without Larsen PS Priming Slurry, 2 N/mm² with Larsen PS Priming Slurry.
Modulus of elasticity	19400 MPa.
Characteristics	Pre-blended dry powder.
Adhesive strength designation	2 N/mm² with Larsen brush applied to underside of paving elements and to surface of concrete base or structural slab.
Application temperature	+3℃ to +30℃.
Bed height	30–75 mm per pass.
Cure time	Light foot traffic: after 12 hours. Vehicle traffic: after 1–2 days (depending on site conditions).
Yield - Concrete	624 L (approximately) per 1.2 MT.
Dry density	2100–2200 kg/m³.
Shrinkage	0.02–0.04%.
Flexural strength	7.8 MPa.
Product Reference	Larsen FBC Permeable High Performance Bedding Mortar.

Sustainability data

Contains Red List materials	No
Country of material origin	United Kingdom
Country of product manufacture	United Kingdom
Material	Cementitious
Recyclability	Recyclable
