FBC Eco BS 7533 part 7, Type B Bedding Mortar

Name: FBC Eco BS 7533 part 7, Type B Bedding Mortar
Brand: Larsen Building Products
SKU: 2raNAar9C3Xf7ZLwkeotqi

Verified by manufacturer 11 days ago

Larsen Building Products

Product certifications:

ISO 9001 Quality Management
Certificate type
Renewable Obligation Certificate (ROC)
Certificate type

Fine bedding concrete specifically designed to meet or exceed the requirements of BS 7533, Part 7, Type B bedding mortar.

Jump to:

+44 (0)28 9077 4000 Website

Application

Suitable for all types of paving including porcelain (>16 mm) when used with Larsen PS primer.

BS 7533 / BS7533 compliant.

Description

Larsen Streetscape FBC Eco is a fine bedding concrete specifically designed to meet or exceed the requirements of BS 7533. Manufactured from a controlled blend of aggregate, cement and GGBS it only requires the addition of water to produce a BS 7533 compliant bedding mortar for the laying course.

Features and benefits:

BS 7533 compliant.
Eco - reduced carbon.
Available in: 25 kg bags, 1.2 tonne weatherproof bulk bags or bulk silos.

General information

Color	Grey
Finish	Textured
Material	Cementitious
Shape	Formless
Length	Bespoke
Width	Bespoke
Height	Bespoke
Warranty description	40 year

Uniclass	Pr_20_31_16_29 Fine bedding concretesPrimary
CAWS	M40/32 Mortar bedding M40/570 Mortar bedding

Specification data - Fine bedding concretes

Standard/ performance requirements	To BS 7533-4:2006, BS 7533-7:2010, BS 7533-10:2010 and BS 7533-12:2006.
Consistency	Pre-blended dry powder.

WaterContent	1.8–2 L per 25 kg.
Materials	Cementitious.
Typical compressive strength	≥35 MPa.
Mortar designation	To BS 7533-7:2010 Type A and Type B compliant.
Working temperature	2ºC–30ºC.
Working time	60 minutes. Manufacturer guidance Approximate time.
Adhesion strength	1 N/mm² without Larsen PS Priming Slurry, 2 N/mm² with Larsen PS Priming Slurry.
Modulus of elasticity	17000–18000 MPa.
Permeability	Allows the passage of water.
Characteristics	Pre-blended dry powder.
Adhesive strength designation	2 N/mm² with Larsen brush applied to underside of paving elements and to surface of concrete base or structural slab.
Application temperature	+3℃ to +30℃.
Bed height	30–75 mm per pass.
Yield - Concrete	13 L (approximately) per 25 kg.
Cure time	Light foot traffic: after 12 hours. Vehicle traffic: after 1–2 days (depending on site conditions).
Dry density	2100–2200 kg/m³.
Shrinkage	0.02–0.04%.
Flexural strength	6 MPa.
Product Reference	Larsen FBC High Performance Bedding Mortar.

Sustainability data

Contains Red List materials	No
Country of material origin	United Kingdom
Country of product manufacture	United Kingdom
Material	Cementitious
Recyclability	Recyclable
