Corbel Vent
Verified by manufacturer 7 days ago
Designed for use with corbelled brickwork details.
Application
- For roof eaves ventilation.
- On roofs where ventilation equivalent to a continuous 10 mm opening is required.
- On roofs where the eaves are finished with corbelled masonry.
- On roofs which do not incorporate a soffit board or fascia board.
Description
Designed for use with corbelled brickwork details.
Features and benefits:
- Efficient, very unobtrusive and easy to fit.
- Superior strength construction - will carry the weight of the bottom row of tiles.
- Can be installed without having to drill the brickwork by using the special fixing clips provided and building them into the perp mortar joints.
- 4 mm-wide ventilation slots comply with BS 5250:2011.
- Durable and totally resistant to decay.
- UV stabilized and colourfast.
- Supplied in 2.4 m lengths with a set of eight fixing clips per length.
Quality:
- Satisfies all NHBC requirements.
- Manufactured to BS EN ISO 9001 and BS EN ISO 14001.
- Complies with all relevant Building Regulations.
- Meets all relevant British Standards.
General information
Color | Black |
Material | PVC-U |
Length | 2400 mm |
Width | 25 mm |
Height | 45 mm |
Uniclass | |
CAWS | H60/355 Ventilated eaves with separated grilles/ trays H60/47 Detailing at eaves H61/355 Ventilated eaves with separated grilles/ rays H61/47 Eaves H62/355 Ventilated eaves with separated grilles/ trays H62/47 Eaves H65/355 Ventilated eaves – separated grilles/ trays H65/47 Eaves |
SKU Code | 3012 |
Specification data - Strip ventilators
Purpose | For use with corbelled brickwork details. |
Ventilation opening | 10 000 mm²/m. Guidance for specification option: 4 mm-wide ventilation slots. |
Colour | Black. |
Sustainability data
Material | PVC-U |
Literature
Corbel Vent Datasheet
