Name: Bamboo Elegance thermo bamboo decking - Decking System
Brand: Wallbarn Ltd
SKU: 8FeNDVUzkHQSnWCfooppum

Color

Grey

Finish

Other

Guidance for specification option:

Aged effect finishing surface coating that is resistant to UV fading and to staining.

Material

Bamboo

Shape

Rectangle

Length

Bespoke

Width

Bespoke

Warranty description

25 year

Uniclass

Ss_30_20_30_25 Decking systemsPrimary

CAWS

Q37/460 Support pedestals

Q55/395 Support pedestals

Q55/110 Deck

Classification data

System performance

Guidance for specification option:

Consult manufacturer and insert requirements.

Ground preparation

Guidance for specification option:

Consult manufacturer and insert requirements, specify separately or omit.

Barrier membrane

Plastics sheets.

Structure

Foundations

Guidance for specification option:

Consult manufacturer and insert requirement or omit.

Primary structure

Guidance for specification option:

Consult manufacturer and insert requirement.

Subframe

Guidance for specification option:

Consult manufacturer and insert requirement.

Fasteners

Guidance for specification option:

Consult manufacturer and insert requirement.

Deck boards

Material

Bamboo fibre deck boards.

Fasteners

Guidance for specification option:

Consult manufacturer and insert requirement.

Board accessories

Guidance for specification option:

Consult manufacturer and insert requirements or omit.

Guarding

Required.

Guidance for specification option:

Insert requirements.

Not required.

Edge protection

Required.

Guidance for specification option:

Insert requirements.

Not required.

System accessories

Guidance for specification option:

Consult manufacturer and insert requirements or omit.

Samples required

Guidance for specification option:

Consult manufacturer and insert requirements or omit.

Connections

Aluminium joists.

Guidance for specification option:

Aluminium joists mimic the build of traditional timber substructure but with many key advantages:

Can achieve ultra-low height thresholds. As little as 55 mm total buildup depending on board choice.
Will not rot, warp or bend like timber joists.
100% recyclable material.
Aluminium will not expand and contract like timber joists.
Lightweight and easy to work with material.
Special headpiece on our pedestals to accommodate the aluminium joists.
Depending on board choice, we have a number of hidden fixings available – i-Fly, 4 Hook, Remo.

Composite joists.

Guidance for specification option:

Composite joists are sturdy and suitable for use with almost any board on the market.

Will not rot, warp or bend like timber joists.
Dimensions 3600 x 38 x 88 mm.
3.7 kg/m (linear).
Suitable for decking joists/sub-frame.
Compatible with our pedestals to lift to required height.
Depending on board choice, we have a number of hidden fixings available – i-Fly, 4 Hook, Remo.

iDecking EasyChange.

Guidance for specification option:

The EasyChange i-Decking system uses a hidden fixing that allows for the boards to be unlocked using a key. This is suitable for when access to the sub floor for maintenance or repairs is needed.

Sustainable, non-rotting decking system.
Integrated substructure and deck board.
Clean lines, uninterrupted surface.
Composite, bamboo and tropical hardwood options available.
Bare foot friendly.
Suitable for low thresholds (whole system from 83 mm).
Faster, easier installation.
Suitable for domestic or commercial use.

iDecking EasyClick.

Guidance for specification option:

The Easyclick i-Decking system uses a hidden fixing that allows for the boards to be clicked into place. This makes for a dramatically easy and faster installation.

Double aluminium rail substructure system.
Profiled rail clicks into headpiece of adjustable height pedestals without need for mechanical fixings.
Aluminium rail with integrated clips to secure and opposition boards.
Boards extruded with special profiles to fit into clips.
Self-aligning system drastically reduces errors.
Faster installation.
No top fixings mean no surface holes, splits or lifting.

Rails

Single beam with noggins, cross bracing sections of rail fixed with L shaped brackets.

MassDensity

1,200 kg/m³.

Dimensional stability

1.13%.

Manufacturer guidance

Average cumulative value (24 hours of immersion in water at 20°C).

Hardness

To EN 1534, 87 N/mm².

BendingStrength

50.30 MPa.

Modules of elasticity

13,565 MPa.

Biological durability

To EN 350, Class 1.

Guidance for specification option:

Very durable - CEN/TS 15083.

Resistance

To EN 152, Class 0.

Manufacturer guidance

Blue Stain fungi resistance.

Use class

To EN 335, Class 4.

Slip resistance

To DIN 51130, R11 (dry); R10 (wet).

Fire reaction (EN 13501-1)

Bfl-s1.

Guidance for specification option:

Flame propagation index US (ASTM E84) Class A.

Manufacturer guidance

UNI EN ISO 9239, UNI EN ISO 11925-2, UNI EN 13501-1.

Contains Red List materials

Country of product manufacture

China

Recyclability

100%

Classification data
System performance	Guidance for specification option: Consult manufacturer and insert requirements.
Ground preparation	Guidance for specification option: Consult manufacturer and insert requirements, specify separately or omit.
Barrier membrane	Plastics sheets.
Structure	-
Foundations	Guidance for specification option: Consult manufacturer and insert requirement or omit.
Primary structure	Guidance for specification option: Consult manufacturer and insert requirement.
Subframe	Guidance for specification option: Consult manufacturer and insert requirement.
Fasteners	Guidance for specification option: Consult manufacturer and insert requirement.
Deck boards	-
Material	Bamboo fibre deck boards.
Fasteners	Guidance for specification option: Consult manufacturer and insert requirement.
Board accessories	Guidance for specification option: Consult manufacturer and insert requirements or omit.
Guarding	Required. Guidance for specification option: Insert requirements. Not required.
Edge protection	Required. Guidance for specification option: Insert requirements. Not required.
System accessories	Guidance for specification option: Consult manufacturer and insert requirements or omit.
Samples required	Guidance for specification option: Consult manufacturer and insert requirements or omit.
Connections	Aluminium joists. Guidance for specification option: Aluminium joists mimic the build of traditional timber substructure but with many key advantages: Can achieve ultra-low height thresholds. As little as 55 mm total buildup depending on board choice. Will not rot, warp or bend like timber joists. 100% recyclable material. Aluminium will not expand and contract like timber joists. Lightweight and easy to work with material. Special headpiece on our pedestals to accommodate the aluminium joists. Depending on board choice, we have a number of hidden fixings available – i-Fly, 4 Hook, Remo. Composite joists. Guidance for specification option: Composite joists are sturdy and suitable for use with almost any board on the market. Will not rot, warp or bend like timber joists. Dimensions 3600 x 38 x 88 mm. 3.7 kg/m (linear). Suitable for decking joists/sub-frame. Compatible with our pedestals to lift to required height. Depending on board choice, we have a number of hidden fixings available – i-Fly, 4 Hook, Remo. iDecking EasyChange. Guidance for specification option: The EasyChange i-Decking system uses a hidden fixing that allows for the boards to be unlocked using a key. This is suitable for when access to the sub floor for maintenance or repairs is needed. Sustainable, non-rotting decking system. Integrated substructure and deck board. Clean lines, uninterrupted surface. Composite, bamboo and tropical hardwood options available. Bare foot friendly. Suitable for low thresholds (whole system from 83 mm). Faster, easier installation. Suitable for domestic or commercial use. iDecking EasyClick. Guidance for specification option: The Easyclick i-Decking system uses a hidden fixing that allows for the boards to be clicked into place. This makes for a dramatically easy and faster installation. Double aluminium rail substructure system. Profiled rail clicks into headpiece of adjustable height pedestals without need for mechanical fixings. Aluminium rail with integrated clips to secure and opposition boards. Boards extruded with special profiles to fit into clips. Self-aligning system drastically reduces errors. Faster installation. No top fixings mean no surface holes, splits or lifting.
Rails	Single beam with noggins, cross bracing sections of rail fixed with L shaped brackets.
MassDensity	1,200 kg/m³.
Dimensional stability	1.13%. Manufacturer guidance Average cumulative value (24 hours of immersion in water at 20°C).
Hardness	To EN 1534, 87 N/mm².
BendingStrength	50.30 MPa.
Modules of elasticity	13,565 MPa.
Biological durability	To EN 350, Class 1. Guidance for specification option: Very durable - CEN/TS 15083.
Resistance	To EN 152, Class 0. Manufacturer guidance Blue Stain fungi resistance.
Use class	To EN 335, Class 4.
Slip resistance	To DIN 51130, R11 (dry); R10 (wet).
Fire reaction (EN 13501-1)	Bfl-s1. Guidance for specification option: Flame propagation index US (ASTM E84) Class A. Manufacturer guidance UNI EN ISO 9239, UNI EN ISO 11925-2, UNI EN 13501-1.
