AIRTRAK® RV Roll Vent - Roof Ventilation System
Verified by manufacturer 3 days ago
ISO 9001 Quality Management
Certificate type
Roll ventilator designed to ensure that the airpath at the eaves is unobstructed by the insulation where it sits above the wall plate.
Application
For use at the eaves of a roof over 15° where the roof void is to be ventilated. Can be used with rafters at 400 and 600 mm centres.
Description
Roll ventilator designed to ensure that the airpath at the eaves is unobstructed by the insulation where it sits above the wall plate.
General information
Color | Black |
Material | PVC-U Guidance for specification option: Unplasticized. |
Length | 6000 mm |
Width | 350 mm |
Height | 35 mm |
Warranty description | Ten year |
Uniclass | |
CAWS | H60/355 Ventilated eaves with separated grilles/ trays H60/47 Detailing at eaves H61/355 Ventilated eaves with separated grilles/ rays H61/47 Eaves H62/355 Ventilated eaves with separated grilles/ trays H62/47 Eaves H65/355 Ventilated eaves – separated grilles/ trays H65/47 Eaves |
Specification data - Plastics rafter ventilator trays
Style | Roll ventilator. |
Ventilation opening | 25 mm continuous airpath. |
Installation | Manufacturer guidanceRolled out over the rafters directly over the wall plate and nailed in position. For deepfill loft insulation two rows of the RV may be required to maintain the ventilation path. Consult manufacturer's literature for details. |
Sustainability data
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Material | PVC-U Guidance for specification option: Unplasticized. |
Recyclability | Recyclable at end of life |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 50 % |
Expected Life | 30 year |
Third party certifications
ISO 9001 Quality Management
Citation
Literature
AIRTRAK Roof Void Ventilation System 2020
Case studies
AIRTRAK™ - St Johns Chapel
AIRTRAK™ - Coal Drops Yard
Clifton Cathedral
