AIRTRAK® RTV Ridge Tile Ventilator - Roof Ventilation System

Name: AIRTRAK® RTV Ridge Tile Ventilator - Roof Ventilation System
Brand: Nicholson STS Ltd
SKU: fK7o6WL1jgoHGSBsSpkYTc

Verified by manufacturer 4 days ago

Airtrak RTV Ridge Tile Ventilator

Nicholson STS Ltd

Third party certifications:

ISO 9001 Quality Management
Certificate type

Provides ventilation of most ridge tiles using traditional wet laid methods.

Jump to:

+44 (0) 1763 295828 Website

Application

Suitable for providing ventilation to a tiled or slated roof ridge at a pitch of over 25°. To be used in conjunction with the AIRTRAK® LPS Low Pitch Soaker.
E Version: For increased resistance to both wind uplift in exposed locations and corrosion in coastal locations, the ventilator can be supplied in 1.0 mm-thick, 316 grade stainless steel. Where extreme weather conditions are likely, consideration should be given to providing more weathering cover to upstands and slating or tiling to improve the integrity of the detail.
FR Version: To reduce spread of fire through ventilation apertures, the ventilator can be supplied with an intumescent seal.

Note: Standard AIRTRAK® details assume moderate weather conditions. Small amounts of moisture may be admitted under heavy storm conditions. Where more severe weather conditions are likely, consideration should be given to increasing the vertical overlap dimension to upstands and to slating or tiling to improve the integrity of the weathering detail. For slate and tile details the manufacturer also recommends the use of the Airtrak LPS where appropriate. Contact manufacturer for further technical help.

Description

Provides ventilation of most ridge tiles using traditional wet laid methods. Particularly suitable where the existing ridge needs to be retained or on heritage properties where a dry ridge system may be inappropriate.

Features and benefits:

Includes a certified and storm-rated weather strip to the underside, which serves to check wind-driven rain on the face of the tiles or slates and also to seal any fixings through into the top batten.
An expanded stainless steel mesh on the face of the RTV provides a key for the mortar bedded ridge tiles.

General information

Material	Stainless steel Guidance for specification option: Expanded metal lath. Foam Guidance for specification option: Weather strip. Aluminium Guidance for specification option: Pitch soaker. Glass Reinforced Plastic (GRP) Guidance for specification option: Insect mesh.
Length	1000 mm Manufacturer guidance Unit length.
Width	125 mm 175 mm 250 mm Manufacturer guidance Overall girth.
Warranty description	Ten year

Uniclass	Pr_30_59_29_71 Roof ridge ventilator tilesPrimary
CAWS	H60/740 Mortar-bedded and mechanically fixed ridges H60/77 Mortar-bedded and mechanically fixed ridges H61/740 Mortar-bedded and mechanically fixed tile ridges H62/740 Mortar-bedded and mechanically fixed tile ridges H62/77 Mortar-bedded and mechanically fixed tile ridges H65/740 Mortar-bedded and mechanically fixed ridges H65/77 Mortar bedded and mechanically fixed ridges

Specification data - Roof ridge ventilator tiles

Ventilation opening	5 mm continuous air gap equivalent.
Colour	Stainless steel.

Grade	304.
Dimensions	1000 x 125 mm. Guidance for specification option: Unit length x overall girth.
Type	Standard.

Sustainability data

Contains Red List materials	No
Country of material origin	United Kingdom
Country of product manufacture	United Kingdom
Material	Stainless steel Guidance for specification option: Expanded metal lath. Foam Guidance for specification option: Weather strip. Aluminium Guidance for specification option: Pitch soaker. Glass Reinforced Plastic (GRP) Guidance for specification option: Insect mesh.
Recyclability	Recyclable at end of life
Recycled content As defined in clause 7.8 of BS EN ISO 14021	50 %
Expected Life	30 year
