Strong, Fast and Silent motorised curtain track, ceiling, wall, recess mounted, for light to heavy weight curtains up to 65 kg in weight. Designed for commercial and residential applications. The track can also be recessed into the ceiling using a dedicated recess profile.

Features and benefits:

Strong: Can carry up to 65 kg of curtain weight.
Fast: Curtain travel speed: 210 mm/ second. Alternative 150 mm available.
Quiet: Combines a brushless motor, two-component glider and profile coating for silent curtain travel.
Bendable: Standard profiles can be bent to 250 mm radius (minimum); recessed fixing profiles can be bent to a 500 mm radius (minimum).
Stacking: Multiple and asymmetric applications.
Wave: Compatible with Wave, a contemporary curtain heading system which allows curtains to hang in a continuous wave which is smooth, simple and elegant.
Touch and Go: A slight pull on the curtain starts the motor.
Manual Override: Can be used if there is a power failure.
Versatile: Motor can be mounted above or below the track.
Flexible control: Switch, remote, App, Smart.

Motor/ Features:

Ref 9060:

Suitable for all common building automation systems.
Switching by the mains group – no relays required.
Switching by low voltage inputs group (maximum 12 motors) and individual.
Mains 230 V simultaneous or individual operation.
Two programmable scenes (intermediate stops).
Standard status LED indicator.
Can be stopped at any position.
Silent Gliss radio control systems Ref 9960 OR Ref 0450.

Fixing brackets:

Ceiling fix with clamp Ref 3004 – with end fixings 100 mm from end of track; higher edge of profile to room side.
Ceiling fix direct through profile with mounting support plate 10865/profile protector 7002 with end fixings 100 mm from end of track; higher edge of profile to room side.
Recessed fix with recess profile Ref 10862 and fixing wedges Ref 5118 – at 800 mm centres; end wedges to be positioned 200 mm from ends of track.

Fixing:

Track fixings are required at 300–600 mm centres, depending on the curtain configuration.
Fix nylon ceiling clamps Ref 3004 to ceiling.
Fix direct through the profile with mounting support plate 10865 and profile protect 7002.
Fix to wall with brackets 3134-9 and bracket 3041.
Fix in recess with recess profile 10862.

Standard Components:

Track Ref 10580.
Motor 100–250 V a.c.: Ref 9060.
Control systems 9940 or 0450.
Belt Ref 10825, Belt return set Ref 10819, Cover ref 10581; Mask pair stack Ref 10836; Master carrier set Ref 10822; Belt return set Ref 10819; Case holder Ref 10817; Pilot runner set Ref 10828; Pilot runner arm Ref 10837; Roller glider Ref 10840; Overlap arm straight Ref 10820; Overlap arm bent Ref 10821; Overlap arm support set Ref 10826.
