ZI-BOX DUO Roller Blinds - Blackout Double Blind System

Verified by manufacturer 3 days ago

Bandalux Industrial SA Third party certifications:
  • ISO 45001 Health and Safety Management

    Certificate type

  • ISO 9001 Quality Management

    Certificate type

  • QA Certificate

    QA Certificate

    Certificate type

  • GreenGuard Gold

    GreenGuard Gold

    Certificate type

  • ASTM

    ASTM

    Certificate type

  • EPD

    EPD

    Certificate type

Blackout double roller blinds system that combines design and functionality.

Jump to:
+(34) 938 615 179 Website

Application

For indoor use.


Roller blinds particularly suitable for rooms where the light needs to be controlled or prevented.

Description

The Zi-Box Duo roller blinds is a solution that guarantees full control of the luminosity entrance thanks to its double blackout and decorative fabric. An appropriate option for rooms where the user needs, depending on the time of day, to control the light or prevent the entrance of it.


This interior system with box has an exclusive design that consists of an Easy Zip telescopic track with zipper, patented by Bandalux, so that the blackout fabric does not come off. The double blind has an independent drive for improved light control. The Zi-Box Duo is a system with a simple installation, also on irregular surfaces.


Features and benefits:

  • Made with highly resistant materials and components that guarantee durability.
  • Mechanisms and components ensure a seamless roll of the fabric, with a straight and firm drop.
  • Excellent sun protection.
  • Double blind system.
  • Combines decorative and opaque fabrics.
  • The Easy-Zip channels allow improving the opacity of the blackout.
  • Wide range of fabrics available.
  • Easy and simple assembly.
  • Different cassette sizes to join capacity and aesthetics.
  • One and two operating systems.
  • Chain or motor operation.
  • Three year warranty.
  • Child safe system.
  • CE marked.

General information

Color

White

Black

Grey

Guidance for specification option:

Grey and anthracite.

Brown

Ivory

Show more

Finish

Other

Material

Fabric

Aluminium

Stainless steel

Shape

Rectangle

Square

Width

Bespoke

Height

Bespoke

Warranty description

Three year

Uniclass

Pr_30_59_07_72 Roller blindsPrimary

CAWS

N10/70 Blinds

N10/240 Blinds

Specification data - Roller blinds

Standards

To BS EN 13120.

Position

Indoor, frontal.

Indoor, lateral.

Dimensions (minimum width x depth)

-

Manufacturer guidance

Consult manufacturer and insert requirements.

Blinds

-

Material

Fabric.

Guidance for specification option:

Standard - Consult manufacturer's literature and insert requirements.

Insect screen fabric.

Guidance for specification option:

Optional.

Blackout function

Required.

Guidance for specification option:

Consult manufacturer and insert requirements.

Not required.

Finish

-

Manufacturer guidance

Consult manufacturer's literature and insert requirements.

Colour

-

Manufacturer guidance

Consult manufacturer's literature and insert requirements.

Pattern

Digital Printing.

Guidance for specification option:

Consult manufacturer and insert requirements.

Not required.

Tube

-

Material

Extruded aluminium.

Tube covers

-

Material

Extruded aluminium.

Manufacturer guidance

Cassette frame.

Colour

White, RAL 9016.

Black, RAL 9011.

Brown, RAL 8019.

Grey, RAL 9006.

Ivory, RAL 1013.

Anthracite, RAL 7016.

Manufacturer guidance

Qualicoat lacquer or anodized Qualanod.

Operation

Manual, chain-chain.

Motor-motor.

Guidance for specification option:

Consult manufacturer's literature for motorized options and insert requirements.

Chain-motor.

Guidance for specification option:

Chain (front shade); motor (rear shade). Consult manufacturer's literature for motorized options and insert requirements.

Mechanism endurance

To BS EN 13120, class 3.

Accessories

Child safety chain retainer.

Guidance for specification option:

Standard security device served by default.

Safekids.

Guidance for specification option:

Optional child safety system - highly efficient as it cannot be taken apart or tampered with and guarantees that the chain will not detach from the wall preventing from strangulation.

Personalisation.

Guidance for specification option:

Consult manufacturer and insert requirements.

Metallic chain.

Not required.

Bottom bar

Hidden, Ø20.

Guidance for specification option:

Front shade (served by default).

Hidden, Ø30.

Guidance for specification option:

Front shade.

Visible, Slim 35.

Guidance for specification option:

Front shade.

Manufacturer guidance

Rear shade: Slim 35 mm.

Components

White, RAL 9016.

Black, RAL 9011.

Brown, RAL 8019.

Grey, RAL 9006.

Ivory, RAL 1013.

Show more

Manufacturer guidance

Components colour.

Cassette, side channels, chains, accessories and hembar in the same matching RAL colour to cassette.

Cassette size

85 mm.

100 mm.

136 mm.

Operating system

Double drop with double support.

Brackets

Ceiling.

Wall.

Guidance for specification option:

Incompatible with frontally installed channels.

Not required.

Manufacturer guidance

Optional brackets.

Brackets are visible and include fastening bolt.

Sustainability data

Contains Red List materials

No

Country of material origin

Spain

Country of product manufacture

Spain

Material

Fabric

Aluminium

Stainless steel

Recyclability

Yes, Aluminum and Fabrics

Guidance for specification option:

Aluminum and Stainless Steel is 100% recyclable, an un-limited number of times, without losing or diminishing its chemical or mechanical characteristics. For this reason, the life cycle of an aluminum or stainless steel product tend to be circular, this concept being called “cradle-to-cradle”, currently used to reach an efficient economy in the use of resources, that takes advantage of all materials at the end of their useful life as raw materials.

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

95 %

Guidance for specification option:

Bandalux’s extruded aluminum profiles and tubes have 95% recycled content.

Bandalux’s laminated aluminum has between 45% and 65% recycled content.

90% or our contract fabrics collection has 2% up to 100% recycled content.

Third party certifications

BIM objects

Platform Compatible Version
Revit
-

1

Third party certifications

ISO 45001 Health and Safety Management

ISO 45001 Health and Safety Management

ISO 45001:2018

ISO 9001 Quality Management

ISO 9001 Quality Management

ISO 9001:2015

QA Certificate

Company, Systems, Fabrics and Motors Certificates and Warranties

GreenGuard Gold

GreenGuard Gold

Polyscreen 351 - Greenguard

ASTM

ASTM

Anti-bacterial certificate

GreenGuard Gold

GreenGuard Gold

Polyscreen 403 - Greenguard

GreenGuard Gold

GreenGuard Gold

Polyscreen 550 - Greenguard

EPD

EPD

Polyscreen - EPD

Literature

ZI-BOX DUO Roller Blinds

ZI-BOX DUO Roller Blinds

Polyscreen 351 Fabric - Data Sheet

Polyscreen 351 Fabric - Data Sheet

Polyscreen 403 Fabric - Data Sheet

Polyscreen 403 Fabric - Data Sheet

Polyscreen 550 Fabirc - Data Sheet

Polyscreen 550 Fabirc - Data Sheet

Mega Blackout Fabric - Data Sheet

Mega Blackout Fabric - Data Sheet

Airpure Treatment for Roller Blinds

Airpure Treatment for Roller Blinds
