Wonder Yarn 36 - Artificial grass
Verified by manufacturer 13 days ago
Wonder Yarn 36 mm available in 2 and 4 m widths and suited for high traffic areas including lawns, play areas and roof gardens.
Application
Suitable for use in high traffic areas including landscaping, play and roof gardens as part of the EverRoof classified system.
Description
Wonder Yarn uses a state of the art 'W' shaped yarn to offer the ultimate recovery properties .
The 'W' yarn is exclusive to the Evergreens UK Group and has been designed to stand up, so when compared to more traditional flat yarns, Wonder Yarn will show less signs of flattening over time.
Features and benefits:
- Mix of light and dark green plus biege thatch.
- Yarn quality: Environmental friendly, free of lead and cadmium.
- Roll widths available in 2000 or 4000 mm.
- Critical fall height (tested to BS EN 1177): 1.1 m (no underlay), 1.5 m (with Lazypad 25 mm) and 2.5 m (with Lazypad 50 mm underlay).
- Tested for UV stability to DIN 53387 and flammability to BS 4790.
- Tested to BROOF(t4) as a component of the EverRoof system.
General information
Color | Green Guidance for specification option: Mix of light and dark green. |
Finish | Tufted |
Material | Polyethylene Guidance for specification option: (8000/ 8 dTex) polyethylene monofilament straight. |
Shape | Other |
Length | Bespoke |
Width | 4000 mm 2000 mm |
Height | 36 mm |
Warranty description | Ten year |
Uniclass | |
CAWS | Q26/350 Synthetic grass surfacing |
Specification data - Synthetic grass surfaces
Pile | |
Type | Tufted. |
Material | Mixed polyethylene and polypropylene.Guidance for specification option: (8000/ 8 dTex) polyethylene monofilament straight and (5000/ 8 dTex) polypropylene monofilament curled (UV stabilized). |
Height | 36 mm (± 10%).Manufacturer guidancePile height. |
Weight | 2758 g/m² (± 100 g/m²).Manufacturer guidanceTotal weight. |
Colour | Mix of light and dark green plus caramel thatch. |
Width (minimum) | 2000 mm.4000 mm.Manufacturer guidanceRoll width (± 20 mm). |
Radius of ignition | |
Standard | To BS 4790. |
Roll length | 25 m. Other. Guidance for specification option: Larger roll lengths available in request. |
Primary backing | 100% polypropylene, black. Guidance for specification option: UV stabilized, weight 172 g/m². |
Secondary backing | Black latex compound with a base of SBR, with drainage holes. Guidance for specification option: 836 g/m². |
Water permeability | 60 L/min/1000 mm. |
Weight | 1750 g/m² (± 10%). Manufacturer guidanceFace weight. |
Gauge | 3/8 gauge. Manufacturer guidanceTuft gauge. |
Colour fastness | Bleu-scale > 7, Grey-scale > 4. Manufacturer guidanceXenon test. |
Infill | 8 kg/m². Manufacturer guidanceSand fill. |
Stitches per m² | 15,750. Guidance for specification option: Per 100 mm linear: 15.0. |
UV stabilization | To DIN 53387. |
Standard | To BS EN 1177, 1.1 m (no underlay), 1.5 m (with Lazypad 25 mm) and 2.5 m (with Lazypad 50 mm underlay). Manufacturer guidanceCritical fall height. |
Accessories | Not required. Joining tape. Lazyfix adhesive. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Netherlands |
Country of product manufacture | Netherlands |
Recyclability | Can be recycled at end of life at GBN in the Netherlands. |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 0 % |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 IFC | IFC2X3 | 2 |
 Revit | Revit 2016 | 3 |
