Wet Suit 2-Part - Fully Self-Adhered Cold-Spray Membrane
Verified by manufacturer 8 months ago
Miami-Dade County Product Control Approved
Certificate type
New Zealand Building Code
Certificate type
City of Los Angeles Building Code
Certificate type
NCC Volume 1
Certificate type
NCC Volume 2
Certificate type
BS EN 13501-1
Certificate type
A fully self-adhered, cold-spray, fluid applied membrane. Versatile for above and below-grade applications.
Application
WetSuit® is designed for exterior and interior vertical and horizontal waterproofing, roofing, and environmental barrier applications. Typical applications include:
- Split slab and structural slab waterproofing: Plaza decks, balconies, roof decks.
- Sea walls, dams and retaining walls: Green roofs, blue roofs, terraces and planters.
- Corrosion protection, wall restoration: Below grade foundations and walls.
- Impermeable air and vapour barriers: Ponds, fountains, pools, tanks, containment.
- Marine and industrial applications: New and retrofit roofing over capsheet/APP, single-ply (TPO, PVC, EPDM), metal roofs, built-up roofs, plywood, spray foam and many coatings.
Description
WetSuit® 2 Part is a patented VOC-free, instant-set, water-based two-component cold-spray applied, fully-adhered, auto-terminating bituminous high grade rubber membrane suitable for a variety of waterproofing, roofing, air/ vapour barrier and protective applications. WetSuit® 2 Part builds to any millage in a single pass application resulting in rapid application and a variety of vertical and horizontal uses.
Features and benefits:
- Versatile: proven in waterproofing, roofing, and air/vapour barrier applications, hydrostatic and dry, exposed and buried, interior and exterior, vertical and horizontal.
- Durable, 2124% elongation and memory.
- Highly resistant to puncture and impact, approved for foot traffic, excellent weathering and UV-resistance performance.
- Can withstand ponding water indefinitely.
- BRoof T4 fire-rated and self-extinguishing.
- High adhesion with a water-based Wetsuit® primer over a wide variety of substrates eliminates laborious preparation; the system is easy to clean, and components mix externally.
- True waterproofing performance.
- Accelerated spray is 80% cured in 3 seconds, immediately tack free.
- Environmentally friendly, low-impact install.
- Simple preparation work. Requires fabric reinforcement only on a gap, transitions, and joints, no torches or melting pots.
General information
Color | Black |
Finish | Matt |
Material | Rubber |
Shape | Other Manufacturer guidanceCan be custom designed to any shape. |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | 20 year Manufacturer guidanceA 120 year warranty can be provided for underground application. |
Uniclass | |
CAWS | J30/110 Cold-applied tanking J30/130 Cold-applied damp-proofing J30/10 Cold-applied damp-proofing |
Specification data - Cold-applied polymer-modified bitumen waterproof coatings
Third-party certification | CE marked, BRoofT1, BRoofT2, BRoofT3, DRoofT4, Euroclass E, Class A. |
Modifier | Polychloroprene (CR). |
Colour | Black. |
VOC content | 0%. |
Elongation | To ASTM D412, 2124%. |
Tensile strength | To ASTM D412, 363.2 Psi. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Manufacturer guidanceMaterial originates from various parts of the world, depending on availability of supply. However, information can be provided. Once an order has been placed, we will be able to identify the source of the material for the specific batches. |
Country of product manufacture | United States |
Recyclability | Manufacturer guidanceThe WetSuit could be recycled in the same way as you would recycle old tires. The recycled material can be used in a: "Tire Derived Aggregate"; "Rubber Modified Asphalt"; and "Tire Derived Fuel". |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 0 % |
Third party certifications
Miami-Dade County Product Control Approved
Florida Building Code and the High Velocity Hurricane Zone of the Florida Building Code
New Zealand Building Code
Compliance with New Zealand Building Code
City of Los Angeles Building Code
Methane Barrier
New Zealand Building Code
Adhesion Test (Concrete, Strand Board, Metal, ED Torch on Membrane)
New Zealand Building Code
Asbestos Encapsulation
NCC Volume 1
Australia Building Code
New Zealand Building Code
Cold Temperature Pliability
NCC Volume 1
Compliance with NCC Volume 1
NCC Volume 2
Compliance with NCC Volume 2
New Zealand Building Code
Cyclic Movement of WetSuit Bridging a Joint on Plywood Substrate
BS EN 13501-1
Fire Safety Certificate
BS EN 13501-1
Fire Safety Certificate
New Zealand Building Code
Hydrostatic Resistance
New Zealand Building Code
New Zealand Building Code
Literature
NCC-EN-TDS - Wetsuit 2-part
Specification Drawing of Expansion Joint for Roofing
WetSuit Roof Drain
Standard Outside Corner Waterproofing Transition
Standard Planter Waterproofing
Standard Waterproofing System
Standard Waterproofing System with Drainage Matt
Waterproofing Between Slab
Waterproofing Deck System - Pavers on Pedestals
WetSuit Paver System with Seam or Crack
WetSuit Roofing Gutter Transition
WetSuit Roofing Penetration (Counter-Flashing Method)
WetSuit Roof Seam or Crack Bridging (without Top Coat)
WetSuit Standard Roof System (without Top Coat)
WetSuit Standard Roof System with Top Coat
Waterproofing Horizontal Penetration (counter-flashing)
WetSuit Waterproofing Seam or Crack Bridging
Waterproofing Transition with Cant
WetSuit Waterproofing Vertical Penetration (with silicone)
Waterproofing Vertical Penetration (counter-flashing)
Asbestos Roof Encapsulation System (reinforced)
Asbestos Roof Encapsulation System
WetSuit Vapour Barrier System
WetSuit Vapour Barrier System (Seam or Crack bridging)
Combined Gas Barrier and Waterproofing on Compacted Soil
Combined Gas Barrier and Waterproofing
Gas Barrier below slab transition to wall
Gas Barrier on Compacted Soil
Standard System for Gas Barrier
Gas Barrier below Slab transition to Wall (alternative approach)
Deck System
Floor to Wall Transition with Steps
Green Roof
Hot Asphalt over WetSuit
Tile and Thin set over WetSuit
Insulated Concrete Framework (including Detailing and Footing)
WetSuit System over Bridge or Garage Parking Deck
