Application

External cladding.

Description

Rivet fixed aluminium cladding panels.

Vitrabond/A2:

Vitrabond/A2 is composed of two aluminium cover sheets sandwiched with a special homogeneous core material. It results in good surface flatness and high workability, with an excellent strength-to-weight ratio.

Suitable for both exterior and interior architectural applications, as well as for industrial and specialty product designs. Applications include exterior cladding, signage, corporate ID, column covers, interior partitions, canopies, equipment enclosures and kiosks.

- Features and benefits:

  • Cost effective.
  • Low maintenance.
  • Robust durability and strength.
  • A2-s1, d0 rated to EN13501-1
  • Lightweight.
  • Wide colour range available.
  • Available in natural zinc, stainless steel, natural aluminium and natural copper finishes.
  • Warranty available up to 20 years - consult manufacturer for details.

VitraDual:

A1 rated, non-combustible, highly impact resistant solid panel aluminium cladding, providing high durability and mechanical benefits. Designed to provide a non-combustible aluminium panel solution that can be fitted as both cassette panels and flat sheets with no oil-canning appearance, offering a cost effective, non-combustible and aesthetically pleasing alternative to other flat sheet panel systems. VitraDual can be combined with Vitrabond cladding panels when required.

The system uses a 2 mm or 3 mm thick cladding panel which is a durable, impact resistant solid panel and can be prefabricated through curving, rolling or perforation. VitraDual uses the Vitrabond/ Vitracore polyvinylidene fluoride or polyvinylidene difluoride (PVDF) coating system which can be colour matched or provided in RAL colours, stone and wood effect finishes. VitraDual cladding panels are prefinished which means they do not need fabrication prior to the coating process.

- Features and benefits:

  • Lightweight - rigid and lightweight, and therefore also easy to install.
  • Non-combustible - A1 rated (to BS EN 13501-1) covering any colour and air gap.
  • Versatile - Can be custom designed into a wide range of shapes and dimensions along with perforated or curved in some applications.
  • Easy to maintain compared to polyester based coatings.
  • CWCT tested and accredited.
  • Highly durable and impact resistant, can be used effectively in high traffic areas.
  • Paint system - uses the highly recognised PVDF KYNAR 500 or FEVE paints known for their high durability, providing the optimum resistance to weather and industrial pollutants.
  • Warranty available up to 30 years - consult manufacturer for details.
  • Extremely Flat - low surface stress.

Applications:

External cladding.

General information
Finish

Anodized

For Vitrabond and VitraDual, insert requirement.

ANTI-BACTERIA Coating

For Vitrabond only, to meet food handling and storage requirements.

FEVE

Natural aluminium

For Vitrabond only.

Natural copper

For Vitrabond only.

Natural zinc

For Vitrabond only.

PVDF KYNAR 500

REPEL

A self-cleaning surface coating.

SCREEN PRINTING

For Vitrabond only, personalized design and imagery.

Stainless steel

For Vitrabond only.

STATIC DISSIPATIVE

For Vitrabond only, designed for IT industries.

VITRAART

For Vitrabond and VitraDual, personalized design and imagery.

VITREFLON V700

For Vitrabond and VitraDual.

Material

Vitrabond/A2: Aluminium with mineral filled core

VitraDual: Aluminium (3000 and 5000 series)

Uniclass 2015 Aluminium cassette panels (Pr_25_71_14_02)
Specification data
Product Reference

Vitrabond/A2 Rivet Fix

A2-s1, d0 limited-combustible fire rating.

VitraDual Rivet Fix

A1 non-combustible fire rating.

Design

Insert requirement.

Thickness

2 mm

For VitraDual only, 5.4 kg/m².

3 mm

For VitraDual only, 8.1 kg/m².

4 mm

For Vitrabond/A2 only, 8.3 kg/m².

Special order

For Vitrabond and VitraDual, insert requirement.

Panel size -
Width

1250 mm

1500 mm

Special order

Insert requirement, available 900–1800 mm.

Length

2500 mm

3200 mm

4000 mm

Special order

Insert requirement, available up to 6500 mm.

Edges

Natural

Insert requirement, consult manufacturer's literature for information.

Finish

Anodized

For Vitrabond and VitraDual, insert requirement.

ANTI-BACTERIA Coating

For Vitrabond only, to meet food handling and storage requirements.

FEVE

Natural aluminium

For Vitrabond only.

Natural copper

For Vitrabond only.

Natural zinc

For Vitrabond only.

PVDF KYNAR 500

REPEL

A self-cleaning surface coating.

SCREEN PRINTING

For Vitrabond only, personalized design and imagery.

Stainless steel

For Vitrabond only.

STATIC DISSIPATIVE

For Vitrabond only, designed for IT industries.

VITRAART

For Vitrabond and VitraDual, personalized design and imagery.

VITREFLON V700

For Vitrabond and VitraDual.

Colour

Insert requirement from Valcan colour charts.

Standard product features

Material:

  • Vitrabond/A2: Aluminium with mineral filled core.
  • VitraDual: Aluminium (3000 and 5000 series).

Fixing:

Panels are cut and installed as flat sheets with rivets used to attach the panels to the Vitrafix carrier system, colour matched fixings are available from the Vitrafix range. Joint widths are typically 8–10 mm to allow for ventilation as a rainscreen system and panels can be installed as flat of curved according to design intent.

Fire rating (to BS EN 13501-1):

  • Vitrabond/A2: A2-s1, d0 limited-combustible.
  • VitraDual: A1 non-combustible.

Technical characteristics:

Dependent on product and thickness, consult manufacturer for information.

Product Options

Finish:

It is possible to re-anodize Vitrabond in custom colours or designs - consult manufacturer for details.

Design:

Panels can be custom designed into a wide range of shapes and dimensions along with perforations or curves in some applications. Consult manufacturer for information.
