VETROFLAM - Fire protection glass

Name: VETROFLAM - Fire protection glass
Brand: Vetrotech Saint-Gobain UK
SKU: icK4SZUQbHjqDEdJwHMokr

Verified by manufacturer 4 months ago

VETROFLAM laminated glass

Vetrotech Saint-Gobain UK

Fire Resistant Glass

Jump to:

+44 (0)24 7654 7620 Website

Application

Developed specifically for integrity and radiation applications, which can be used for internal and external installations such as:

Partitions;
Fixed glazing;
Fire doors;
Overhead glazing;
Roof glazing;
Facades;
Escape routes.

Description

VETROFLAM is a fire protection glass. It can be installed monolithic, laminated or as double glazed units, particularly in overhead areas, where buildings are close to each other, or in largely glazed stairwells that have fire protection requirements.

VETROFLAM is particularly suitable to prevent the spread of fire in multi-storey buildings. For sloping and roof glazing applications, SGG VETROFLAM CLIMALIT and SGG VETROFLAM CLIMAPLUS can be combined with VETROFLAM STADIP. VETROFLAM products can be used in various frame and profile systems including steel and aluminium. The installation of VETROFLAM has to be installed in accordance with Vetrotech Saint-Gobain's guidelines. CE compliant.

Features and benefits:

6 mm thickness for E30 and EW30.
One-sided fire protection.
High light transmission values of up to 82%.
Low weight product, for easy handling.
Limited surface wall area possible.
Symmetrical 1(C)1 impact resistance (EN 12600).
Secure handling and installation with less breakage.

General information

Color	Clear
Material	Glass Guidance for specification option: Fire resistant toughened safety glass.
Shape	Other Guidance for specification option: Shapes available upon request.
Length	Bespoke
Width	Bespoke
Height	Bespoke
Warranty description	Five year Guidance for specification option: Minimum five years and extended depending on application

Uniclass	Pr_25_71_33_46 Laminated glass sheetsPrimary Pr_25_71_33_88 Thermally toughened glass sheets
CAWS	L40/510 Fire-resistant channel glazing – solid section channel L40/505 Fire-resistant tape/ Strip glazing L40/515 Fire-resistant channel glazing – plastics/ elastomeric channel L10/560 Glazed screen system L40/65 Fire-resistant tape/ Strip glazing L40/75 Fire-resistant channel glazing – solid section channel L40/80 Fire-resistant channel glazing – plastics/ elastomeric channel

Specification data - Laminated glass sheets

Laminate glass type	Laminated. Guidance for specification option: Standard. VETROFLAM / SGG PARSOL. Guidance for specification option: Solar control. VETROFLAM / SGG PLANITHERM ULTRA. Guidance for specification option: Thermal control. VETROFLAM / SGG STAPID SILENCE. Guidance for specification option: Acoustic. VETROFLAM CLIMALIT/ SGG VETROFLAM STADIP. Guidance for specification option: Sloping and roof glazing applications. VETROFLAM CLIMAPLUS. Guidance for specification option: Sloping and roof glazing applications.
Thickness	Manufacturer's standard.
Body colour	Clear.
Coating	-
Type	Heat reflective.
Colour or effect	Clear. Obscure. Printed. Guidance for specification option: Insert requirements.
Performance requirements	-
Fire resistance	-
Integrity	E60. E30.
Radiation	W60. W30.
Light	Contact Vetrotech for more information. Guidance for specification option: Consult manufacturer for details.
Solar control	Contact Vetrotech for more information. Guidance for specification option: Consult manufacturer for details.
Total shading coefficient	Contact Vetrotech for more information. Guidance for specification option: Consult manufacturer for details.
Sound attenuation	Contact Vetrotech for more information. Guidance for specification option: Consult manufacturer for details.
Impact resistance	Symmetrical 1(B)1 impact resistance (EN 12600).

Thermal insulation	Contact Vetrotech for more information. Guidance for specification option: Consult manufacturer for details.

Sustainability data

Material	Glass Guidance for specification option: Fire resistant toughened safety glass.
Recycled content As defined in clause 7.8 of BS EN ISO 14021	30 % Guidance for specification option: Glass should have a minimum recycled content of 30%
