POLYGARD ATTACK
POLYGARD ATTACK
High-security laminated glass (also available in IGU) incorporating polycarbonate layer for a thinner, lighter solution.
Application
POLYGARD is part of the PROTECT range used in scenarios where three main types of risks needs to be considered:
- Physical attack, both planned attacks and opportunistic damage (such as vandalism and theft);
- Ballistic impact (firearms of various calibres including handguns, rifles and shotguns);
- Explosion impact (satchel or car bombs).
Description
POLYGARD offers supreme protection against all forms of attack. Unlike other attack-resistant glass, it offers a lighter, narrower glazing solution with enhanced flexibility due to the addition of polycarbonate.
POLYGARD includes both splintering and non-splintering options without any compromise in essential transparency. A multifunctional product that can be combined with other glass products.The installation of POLYGARD must be installed in accordance with Vetrotech Saint-Gobain's guidelines. CE-compliant.
General information
Color | Clear |
Material | Glass Polycarbonate |
Shape | Other Guidance for specification option: Shapes available upon request |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | Five year Guidance for specification option: Minimum five years and extended depending on application |
Uniclass | |
CAWS | L40/372 Bead-fixed insulating glass units – loadbearing tapes/ synthetic rubber and sealant capping L40/380 Bead-fixed insulating glass units – solid bedding, outside bead L40/381 Bead-fixed insulating glass units – solid bedding, inside bead L40/250 Bead-fixed single glazing – tape and sealant L40/230 Bead-fixed single glazing – non-setting compound L40/310 Bead-fixed single glazing – tape, sealant and trim L40/350 Bead-fixed single glazing – curing compound and trim L40/330 Bead-fixed single glazing – capping L40/260 Bead-fixed single glazing – extruded gasket L40/371 Bead-fixed insulating glass units – cellular adhesive/ mastic tape L40/370 Bead-fixed insulating glass units – insert gasket sections |
Specification data - Laminated glass sheets
Laminate glass type | Security, manual attack. |
Thickness | ≥15–21 mm dependent on product. |
Body colour | Clear. |
Coating | |
Type | Low e and solar control coatings available upon request. |
Colour or effect | Clear.Obscure.Printed. |
Performance requirements | |
Light | Contact Vetrotech for more information. |
Solar control | Contact Vetrotech for more information. |
Total shading coefficient | Contact Vetrotech for more information. |
Sound attenuation | Contact Vetrotech for more information. |
Impact resistance | Contact Vetrotech for more information. |
Security | To EN 356, P6B-P8B security classification. |
Composition | Single. Double glazed unit. POLYGARD / SGG COOL-LITE double glazed unit. Guidance for specification option: Solar control. POLYGARD / SGG CLIMAPLUS. Guidance for specification option: Low E. POLYGARD / CONTRAFLAM - single/ double. Guidance for specification option: Fire protection/ security glass. |
Sustainability data
Material | Glass Polycarbonate |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 30 % Guidance for specification option: Glass should have a minimum recycled content of 30% |
