VEBOX Single - Storage Cabinet
Verified by manufacturer over a year ago
VEBOX-01-COMPACT-SINGLE Storage Cabinet
VEBOX-01-COMPACT-SINGLE Storage Cabinet
Car park storage cabinet.
Application
Storage for standard household and commercial goods, such as:
- Bikes
- Suitcases
- Golf bags
- Toys
- Clothing
- Archive boxes
- Furniture
Description
Free standing or fixed storage cabinet for use in car park spaces or other areas in car parks or buildings.
Features and benefits:
- Cantilevered.
- Two-leg design.
- Contents maximum weight 200 kg.
Fire Performance:
- Manufactured from A1/A2 materials.
- Whole unit (box and legs) fire tested by the Fire Protection Association (UK) as delivering over 60 minutes internal fire protection.
General information
Color | White Grey Other |
Finish | Coated |
Material | Steel |
Shape | Rectangle Guidance for specification option: Rectangular cube. |
Length | 2300 mm |
Width | 1100 mm |
Height | Bespoke |
Warranty description | Six year Guidance for specification option: Full unit warranty. Either defective part or full unit replacement. |
Uniclass | |
CAWS | N10/220 Lockers Q50/212 Cycle lockers |
SKU Code | VEBOXSINGLE01 |
Specification data - Lockers
Locker type | Storage. |
Dimensions | 2300 x 1100 x 2000 mm. Guidance for specification option: Box: 2300 x 1100 x 800 mm. Leg: 2300 x 1100 x 1000-1500 mm (adjustable). |
Material | Galvanized steel. Guidance for specification option: Box: 1.5 mm thick. Legs: 4 mm thick. |
Finish | Wet paint coating. Intumescent coating. Guidance for specification option: For maximum fire and corrosion protection. |
Colour | White and grey. Guidance for specification option: Box: RAL 9010. Legs: RAL 7040. Standard RAL. Guidance for specification option: Any standard RAL available. |
Fittings | Shelves. |
Integral accessories | Key lock. Guidance for specification option: Stainless steel hook bolt Europrofile deadlock. Smart lock. Guidance for specification option: Type specified subject to intended building security access system installed at site. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Europe |
Country of product manufacture | United Kingdom |
A1-A3 (production stage) | Embodied carbon as defined in BS EN 15804 |
Normalised unit | |
Declared unit | 885.9 Self-declared Lower emissions Guidance for specification option: Offset to Net Zero via tree planting - 1 tree per 3 units. |
Recyclability | Galvanised steel |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 0 % |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 IFC | - | 1 |
 Revit | - | 1 |
