Universal Louvre - 2UL
Verified by manufacturer 6 days ago
Universal Louvre 2UL/SH
Universal Louvre 2UL/SH
A double‑bank roll‑formed or extruded louvre system delivering high airflow and improved rain protection – suitable for plant rooms and facade screening.
Application
Suitable in applications such as:
- Rooftop plant room enclosures.
- Air intake louvres for HVAC and ventilation systems.
- Industrial and commercial buildings needing both airflow and rain defence.
- Architectural facades requiring concealed or integrated drainage.
Description
Colt 2UL is a versatile double‑bank louvre system offering a balance of enhanced rain defence and strong airflow performance. Available in shallow (50 mm) or deep (100 mm) blade pitches, it’s suitable for plant room screening and architectural facades. It features concealed drainage via hollow mullions and a clip‑on design for thermal movement, it delivers durable, maintenance‑free performance in challenging weather conditions.
Features and benefits:
- Double‑bank blade design boosts rain defence while maintaining airflow.
- Available in 50 mm or 100 mm blade pitch for design flexibility.
- Integral drainage into vertical mullions improves weather resilience.
- Clip‑on blade construction accommodates thermal movement, simplifies install.
- Corrosion‑resistant aluminium, galvanized steel, or stainless materials.
- Supports architectural integration with accessories like guards and panels.
Performance ratings:
- Rain defence classification: Class A to Class D depending on air velocity (tested to BS EN 13030:2001).
- Aerodynamic classification: Class 3 (Cv approx. 0.21).
- Airflow resistance: Low to moderate resistance with enhanced weather protection.
- Free area: 57% (varies by size and pitch) using industry standard measurement.
Materials and finishes:
- Materials:
- Aluminium (standard – corrosion-resistant).
- Mild or galvanized steel or stainless steel (custom options).
- Finish iptions:.
- Mill finish.
- Polyester powder-coated to standard RAL colours.
- Anodized aluminium.
- Pre-coated steel to match cladding.
Design and construction:
- Blade type: Double-bank roll-formed blades.
- Blade pitch:
- 50 mm (shallow).
- 100 mm (deep).
- Blade profile: Chevron or aerofoil profile.
- Drainage system: Integrated into hollow mullions for effective rainwater removal.
- Free area: Typically 57% depending on configuration (varies by size and pitch) using industry standard measurement.
- Mounting options: Surface-mounted, recessed, or integrated into cladding.
- Panel sizes: Modular – customisable to suit building design.
- Panel depth: 143 mm shallow and 198 mm deep, not including cill projection.
Accessories and options:
- Bird guards (galvanized or stainless steel mesh).
- Insect mesh and/ or fly guard.
- Blanking or insulated panels.
- Acoustic modules available.
- Doors, turrets, and support structures for larger applications.
Installation and maintenance:
- Supplied pre-assembled or in kit form.
- Designed for fast installation with concealed fixings.
- Clip-on blade system accommodates thermal movement.
- Low maintenance – periodic cleaning recommended to remove debris.
Testing and compliance:
- Tested to BS EN 13030:2001 & HEVAC 4th Edition (Test conditions: 13 m/s wind, 75 mm/hr simulated rainfall) and manufactured under ISO 9001.
- Simulated conditions: 13 m/s wind, 75 mm/h rainfall.
- Aerodynamic classification: Cv Class 2 (approximatley 0.308 inlet/ 0.285 exhaust).
- Rain defence classification:
- Class A at ≤0.5 m/s inlet velocity.
- Class B at 1.0 m/s.
- Class C above 1.5 m/s.
General information
Color | Silver Other |
Finish | Mill Embossed Anodized Coated Powder-coated Manufacturer guidance[Finish, Anodised aluminium, polyester powder coated, acrylic, PVF2, and Stucco and HPS 200] |
Material | Aluminium Steel Stainless steel |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Uniclass | |
CAWS | H11/140 Louvres L10/490 Roof ventilators L10/650 Metal louvres |
Specification data - Louvre screen systems
Classification data | |
Screen framing | Aluminium. Mild steel. Stainless steel. |
Louvres | |
Type | As screen framing. |
Operation | Double bank shallow section, front louvres at 50 mm pitch. |
Blanking panels | None. Single skin aluminium panel, mill finish. Single skin aluminium panel with external decorative polyester powder paint finish to match louvres. Insulated panel. |
Acoustic panels | |
Facing | None. Type R acoustic louvre panels. Guidance for specification option: Optimum acoustic performance with normal pressure drop. Type LP acoustic louvre panels. Guidance for specification option: Normal acoustic performance with minimum pressure drop. |
Banked | |
First bank | None. Type R acoustic louvre panels. Guidance for specification option: Optimum acoustic performance with normal pressure drop. Type LP acoustic louvre panels. Guidance for specification option: Normal acoustic performance with minimum pressure drop. |
Second bank | None. Type R acoustic louvre panels. Guidance for specification option: Optimum acoustic performance with normal pressure drop. Type LP acoustic louvre panels. Guidance for specification option: Normal acoustic performance with minimum pressure drop. |
System accessories | None. Visible frame double door. Visible frame single door. Concealed frame double door. Concealed frame single door. Turret unit(s). Triangular panel(s). Circular panel(s). |
Guards | None. Aluminium bird guard. Galvanized steel bird guard. Aluminium fly guard. Stainless steel insect mesh. Manufacturer guidanceLouvre design should allow for additional resistance to airflow and reduced flow rate. |
Dimensions | Guidance for specification option: Insert requirements or drawing/ schedule reference. |
Configuration | Horizontal. Horizontal inverted. Vertical. |
Texture | Plain. Perforated. Stucco embossed. |
Finish | Mill aluminium. Anodized. Guidance for specification option: Consult manufacturer for options and insert requirements. Polyester powder coated, RAL (total coverage). Guidance for specification option: Consult manufacturer for options and insert colour requirement. All exposed surfaces and edges of components and assemblies are coated, excluding fixings and rivets. Polyester powder coated, RAL (partial coverage). Guidance for specification option: Consult manufacturer for options and insert colour requirement. Only external louvre blades, frames, corners and cills are coated, the remaining components are mill finish. PVF2 (total coverage). Guidance for specification option: Consult manufacturer for options and insert colour requirement. All exposed surfaces and edges of components and assemblies are coated, excluding fixings and rivets. PVF2 (partial coverage). Guidance for specification option: Consult manufacturer for options and insert colour requirement. Only external louvre blades, frames, corners and cills are coated, the remaining components are mill finish. |
Performance | Aerodynamic: minimum performance coefficient (Cv) of 0.308 (inlet) and 0.25 (extract); Rain defence: Class A–D. Guidance for specification option: Aerodynamic: Equivalent to Class 2 to HEVAC 4th Edition. Rain defence: To HEVAC 4th Edition.
|
Sustainability data
Material | Aluminium Steel Stainless steel |
