T77 Aluminium Security Shutter

Name: T77 Aluminium Security Shutter
Brand: Roché Systems Ltd
SKU: c89BMoYUNQ2tEm7G2TDhBt

Verified by manufacturer 13 days ago

Roché Systems Ltd

Double skinned insulated aluminium security roller shutter with 77 mm high slats.

Jump to:

BOS

03330347967 Website

Application

For use in high security domestic and commercial applications.

Description

Double skinned insulated aluminium security roller shutter with 77 mm high slats.

Features and benefits:

The shutter can span up to 5.5 m in width and an area up to 16 m².
Numerous control option variants such as group, remote control or mobile phone activation.

General information

Color	White Brown
Finish	Galvanized Powder-coated Laminated
Material	Aluminium
Shape	Rectangle
Length	Bespoke
Width	Bespoke
Height	Bespoke
Warranty description	One year

Uniclass	Pr_30_59_84_73 Roller shuttersPrimary
CAWS	L20/60 Doors L20/610 Roller shutters/ curtains

Product range	Insulated Roller Shutters

Specification data - Roller shutters

Opening sizes	5500 x 2800 mm. Guidance for specification option: Available up to 4000 mm height depending on width.
Arrangement	Vertical, external face fix. Vertical, internal face fix. Vertical, reveal fix.
Shutter curtain.	-
Lath material	Aluminium. Guidance for specification option: 20 mm thick aluminium double skinned polyester powder-coated with polyurethane foam insulating core, 77 mm in height.
Finish and colour	Powder coated - Brown. Guidance for specification option: Standard. Powder coated - White. Guidance for specification option: Standard. Powder coated - BS. Guidance for specification option: Insert colour code. Powder coated - RAL. Guidance for specification option: Insert RAL colour code. Laminated wood effect. Manufacturer guidance Option to powder coat any RAL/ BS colour or laminate wood effect (surcharge applies). Insert requirement; consult with manufacturer for more information.
Frame and guides	-
Material	Aluminium. Guidance for specification option: Enclosure: Roll formed aluminium with pressure-moulded aluminium alloy end caps. Guide channels/ bottom slat: Extruded aluminium with brush and rubber weather seals.
Finish	Powder coated.
Colour	Brown. Guidance for specification option: Standard colour. White. Guidance for specification option: Standard colour.
Operation	-
Mode	Electric, NRG Econom tubular motor. Electric, Somfy tubular motor. Manual, cord belt. Guidance for specification option: Operation may prove problematic dependent on size. Manual, rod and crank. Guidance for specification option: Operation may prove problematic dependent on size. Manual, spring and lock. Guidance for specification option: Operation may prove problematic dependent on size. Manufacturer guidance Electric shutters are supplied with a single phase tubular motor with internal rocker or external key switch as standard. Numerous control option variants such as group, remote or mobile phone activation are available.
Control	Somfy tubular motor and internal rocker or external key switch as standard. NRG tubular motor and internal rocker or external key switch as standard.
Accessories	None. Crank handle. Manual override facility.
