SureBrick System - Brick Slip Cladding System
Verified by manufacturer 8 days ago
BBA Agrément Certificate
Certificate type
SureBrick brick slip drained and back-ventilated cladding system.
Application
Suitable for use internally and externally in new builds or refurbishment applications.
Description
SureBrick Brick Slip Facade System consists of profiled brick slips which are mechanically fixed into SureBrick rails. The profile of the rails suits the coursing height and they can be mounted horizontally or vertically. The rails are mechanically fixed to a secondary support system to create a drained and vented cavity when applied on an external facade.
The SureBrick Brick Slip Facade System can be used internally without a drained and vented cavity. The horizontal and vertical joints between the profiled brick slips are pointed with mortar.
Features and benefits:
- Robust, brick slips are mechanically restrained.
- Non-combustible components (A1).
- Can incorporate traditional brick detailing.
- Able to receive any 65 mm frost resistant (F2) brick to match local brick types.
- Suitable for new build and refurbishment.
- Flexible system that can be adjusted.
General information
Color | Brown Red Other Blue Beige |
Finish | Brick |
Material | Brick Stainless steel Steel |
Shape | Rectangle Other |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | 35 year Guidance for specification option: Available upon application. Consult manufacturer for details. |
Uniclass | |
CAWS | H92/120 Rainscreen cladding |
Specification data - Drained and back-ventilated rainscreen cladding systems
Classification data | |
Secondary support structure | Standard coated steel SureBrick rails. Stainless steel SureBrick rails. |
Cladding panels | |
Material | 22–90 mm clay brick slips. |
Panel joints | SureBrick pointing mortared joints. |
System accessories | Not required. Brick pistol corners. Special shaped bricks. |
Third-party certification | BBA certified. |
Reaction to fire | To EN 13501-1, A1. |
Weathertightness | To BS EN 12865, 2400 Pa. |
Air leakage | To BS EN 1215, A4. |
Weight | 42–56 kg/m². |
Frost resistance | F2. Manufacturer guidanceFrost resistance of bricks. |
Wind resistance | Serviceability/ Safety, 2400/ 3600 Pa. |
Impact resistance | To CWCT TN 76, Cat B Class 3A. |
Resistance | 1.99 kN. Manufacturer guidanceResistance of retaining tabs ETAG 034. |
ShearStrength | 2.48 kN. Manufacturer guidanceFixings pull through (shear) ETAG 034. |
Sustainability data
Country of product manufacture | United Kingdom |
Material | Brick Stainless steel Steel |
Product certifications
BBA Agrément Certificate
BBA Certificate SureBrick
Literature
SureBrick Brochure
