Sunergy
Verified by manufacturer 6 months ago
Solar control glass with a pyrolytic coating that can be heat treated.
Application
Suitable for sun-facing rooms and buildings looking to reduce solar gain and maintain thermal insulation.
Description
Solar control glass with a pyrolytic coating that can be heat treated.
Features and benefits:
- Easy to process.
- Can be used for curved, coloured or neutral facades.
- Can be used as single-pane, insulating or laminated glazing and heat treated or enamelled.
- Large range of substrate colours available.
- Delivers low light reflection similar to soft coatings.
- High level of light transmission creates a bright daylight atmosphere indoors and gives the facade a particularly transparent quality.
- High thermal insulation: U-values as low as 1.0 W/m²K (in double glazing units in combination with a low-E glass).
General information
Color | Clear Blue Guidance for specification option: Blue and dark blue available. Grey |
Material | Glass |
Uniclass | |
CAWS | H11/742 Heat-soaked thermally toughened glass H13/620 Thermally toughened glass L40/430 Single glazing into grooves – non-setting compound L40/490 Single-sided gasket glazing H13/115 Structural glass assembly H13/630 Laminated glass L10/310 Steel windows L10/210 Wood windows L10/350 PVC-U windows L10/390 Proprietary windows L10/400 Composite windows L10/330 Aluminium windows L10/580 Secondary glazing system L40/530 Internal tape glazing L40/470 Zipper gasket glazing H10/10 Patent glazing L10/20 Steel windows L40/50 Bead-fixed single glazing L40/40 Putty-fronted single glazing L40/55 Bead-fixed insulating glass units – drained and ventilated bead L40/57 Bead-fixed insulating glass units – solid bedding, outside bead L40/58 Bead-fixed insulating glass units – solid bedding, inside bead L40/210 Putty-fronted single glazing L40/250 Bead-fixed single glazing – tape and sealant L40/230 Bead-fixed single glazing – non-setting compound L40/260 Bead-fixed single glazing – extruded gasket L40/310 Bead-fixed single glazing – tape, sealant and trim L40/371 Bead-fixed insulating glass units – cellular adhesive/ mastic tape L40/370 Bead-fixed insulating glass units – insert gasket sections L40/372 Bead-fixed insulating glass units – loadbearing tapes/ synthetic rubber and sealant capping L40/330 Bead-fixed single glazing – capping L40/350 Bead-fixed single glazing – curing compound and trim L40/380 Bead-fixed insulating glass units – solid bedding, outside bead L40/381 Bead-fixed insulating glass units – solid bedding, inside bead L40/410 Single glazing into grooves – extruded rubber/ PVC sections L40/450 Single glazing into grooves – sealant capping H10/115 Patent glazing H11/110 Curtain walling L10/15 Wood windows L10/25 Aluminium windows L10/10 Wood windows L10/31 PVC-U windows L10/33 Proprietary windows L10/30 PVC-U windows L40/90 Internal tape glazing |
Specification data - Annealed glass sheets
General requirements | Glass generally. |
Composition | Manufacturer's standard. |
Thickness | Manufacturer guidanceAvailable in a range of thicknesses, consult manufacturer and insert requirements. |
Body colour | Clear.Blue.Dark Blue.Grey. |
Coating | |
Type | Pyrolytic. |
Performance requirements | |
Fire performance | Manufacturer's standard. |
Light | Manufacturer's standard. |
Solar control | Manufacturer's standard. |
Total shading coefficient | Manufacturer's standard. |
Sound attenuation | Manufacturer's standard. |
Impact resistance | Manufacturer's standard. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Europe |
Country of product manufacture | Europe |
Recyclability | Fully recyclable |
Literature
Solar Control Glass by AGC
