SportsDeck Slimline
SportsDeck Slimline
A sports flooring understructure system.
Application
Sports flooring.
Description
SportsDeck is Reflex Sports' most widely specified performance understructure system. Designed to offer sports quality performance on both uneven and level subfloors. The system is precision machined for Reflex in the U.K. using high quality spruce plywood with a levelling cradle system. SportsDeck is available with a number of different surface options, to create both area and combined elastic sprung floors.
Features and benefits:
- Sport England compliant.
- Meets the requirements of EN 14904.
- FSC® or PEFC® chain of custody certification.
- Variable construction heights.
- Suitable for bleacher seating.
- Low maintenance costs.
General information
Color | Grey |
Finish | Smooth |
Material | Wood Timber Plywood Linoleum |
Length | Bespoke |
Width | Bespoke |
Uniclass | |
CAWS | K21/142 Battened wood sports floor |
Specification data - Battened wood-based rigid sheet floating floor systems
System performance | To EN 14904 A4. |
Subfloor preparation layer | Bitumen Kraft paper (moisture content below 75% RH).Newton Slimline DPM (moisture content above 75% RH). |
Vapour control layer | Bitumen Kraft paper (moisture content below 75% RH).Newton Slimline DPM (moisture content above 75% RH). |
Secondary supports or spacers | Acoustic batten cradles and softwood sections. |
Thermal insulation between battens | Guidance for specification option: Insert as applicable: Rockwool or rigid insulation depending on requirements. |
Flooring | Spruce plywood. |
Standard | To EN 14904. |
Surface finish | SportsDeck Slimline. |
Third-party certification | FSC. PEFC. |
Sustainability data
Country of product manufacture | United Kingdom |
Material | Wood Timber Plywood Linoleum |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
