Single Button Firefighter Microphone DCSF1 with Redundant back up, EN54-16 Certified - 583504.RE - Redundant Fire Brigade Stations
Verified by manufacturer 3 days ago
Single Button Firefighter microphone with redundant transmission route, EN54-16 Certified.
Application
Ideal for high-traffic areas such as Airports, Stadia, Railway stations, Shopping Malls, Theatres, Commercial multi story tower blocks. Essential building usage for emergency guidance and routine communication within buildings with large public gatherings.
Description
The DCSF1 is a digital paging microphone designed for critical public address and voice alarm (PAVA) systems, offering full redundancy in signal transmission for enhanced safety. It features one freely configurable key, two LEDs and a manual fist microphone with a built-in loudspeaker.
Features and benefits:
- High failure safety due to redundant transmission route.
- A light emitting diode, programmable in yellow or red.
- Can be used redundantly as well as non-redundantly.
- Hand-held microphone with built-in loud speaker and acoustic microphone monitoring.
- Connection via single or redundant CAT5 (Fire rated cable) up to 300M in length. can be increase to 20KM by using Fibre optic cable.
- Permanent monitoring of the line to the next interface module.
- 24-bit AD/DA converter.
- EN54-16 Certified
General information
Color | Grey |
Shape | Rectangle |
Length | 40 mm |
Width | 134 mm |
Height | 196 mm |
Uniclass | |
CAWS | V90/590 Equipment |
SKU Code | 583504.RE |
Specification data - Paging microphones
Classification data | |
Standard | To BS EN 54-16. |
Loudspeaker zones | Manufacturer guidanceThe microphone controls a single manual message to all loudspeakers connected to the voice alarm system, it is not circuit dependant. |
Microphone | Hand-held, built-in loud speaker and acoustic microphone monitoring. |
Display features | LED, programmable in yellow or red. |
Connection ports | 2 x RJ45. |
Enclosure | |
Colour | Grey. |
Environmental requirements | Ambient temperature -5°C to 55°C. Air humidity <93% (non-condensing). |
Mounting method | Desktop. |
Accessories | Not required. Dummy plate - 583709. Enclosure for one FB call station DCSF - 584961. Enclosure for two FB call station DCSF undefined - 584962. |
Dimensions | 134 x 196 x 40 mm. Manufacturer guidanceWidth x height x depth. |
Weight | 1.6 kg. |
Literature
Literature type
583504.RE Single Zone Fireman's Microphone EN54-16 Declaration of Performance
583504.RE Single Zone Fireman's Microphone EN54-16
VARIODYN ONE - EN54 Certified Voice Alarm Systems Brochure
VARIODYN D1 + Comprio + VARIODYN ONE-EU Declaration of Conformity
