Aluminium secondary glazing.
Usually used on top of casement windows with multiple openers. Suitable for homes, offices, hotels and schools.
Aluminium secondary glazing. Equal leg/ odd leg with built-in fixing cover. Rollers and cliplocks as standard, hardwood subframes (FF) or overhang (RF) and locking fitch catch.
The low profile design and good thermal and acoustic performance mean that secondary glazing is recommended by both Historic England and the Listed Property Owners Club as a suitable product for improving windows in historic buildings.
Features and benefits:
- Optional features:
Color | Brown White Manufacturer guidanceGlazing: clear. Frame: white, anodized aluminium or brown. Any RAL colour available upon request. |
Finish | Smooth Manufacturer guidance(polyester powder coated) |
Material | Aluminium Glass Manufacturer guidanceTimber sub-frame (optional) |
Shape | Rectangle Manufacturer guidanceArches and shapes available |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | Ten year |
Uniclass | |
CAWS | L10/53 Secondary glazing system L10/580 Secondary glazing system |
Product range |
Dimensions and configurations | Guidance for specification option: Max panel sizes: 1000 x 2000 mm (4 mm); 2000 x 2000 mm (6 mm); 2000 x 2500 mm (6.4 mm). Frame profile: 12 mm. |
Product performance | |
Environmental | |
Acoustic performance rating | Up to 45 dB |
Frame | |
Profile | Seasonmaster slimline aluminium.Guidance for specification option: Standard. Hardwood sub-frame.Guidance for specification option: Optional. |
Finish as delivered | |
Coating | Anodized.Powder coated. |
Colour | Anodized.Any RAL colour.Brown.White. |
Ventilator | Not required.Trickle vent option.Guidance for specification option: Trickle vent option with timber sub-frame. |
Glazing or infill | |
Standard | To BS EN 12150. |
Requirements | 4 mm.6 mm.6.4 mm.Acoustic laminated.Flyscreen.Laminated.Toughened. |
Operation | |
Type | Horizontal sliding. |
Fixing features | Faced fixed.Reveal fixed. |
Third party accreditation | Secured by Design, BlueSky Acoustic, PAS 24:2016, BS 6375. |
Impact resistance | To BS EN 12600, Class 1. |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Material | Aluminium Glass Manufacturer guidanceTimber sub-frame (optional) |
