Screening louvre - Contour SL® Rooftop Screening Louvre

Name: Screening louvre - Contour SL® Rooftop Screening Louvre
Brand: Maple Façades
SKU: kqa4NmmAhdju7LjKfThUo9

Verified by manufacturer 3 days ago

Maple Façades

Third party certifications:

Acclaim Accreditation
Certificate type
Achilles Information Limited - Procurement Management
Certificate type
CHAS
Certificate type
Constructionline Gold
Certificate type
Constructionline
Certificate type
ISO 45001 Health and Safety Management
Certificate type
ISO 9001 Quality Management
Certificate type
Alcumus SafeContractor
Certificate type
FIRAS
Certificate type

An advanced rooftop plant screening solution with a mullion design for long louvre spans. A highly versatile Maple system with different louvre, flashing, corner type and mullion design options.

Jump to:

+44 (0)161 456 6644 Website

Application

Typically used on rooftop locations to hide unsightly HVAC machinery and equipment.

Description

Contour SL140 uses inverted blades at 140 mm pitch to provide visual screening against unsightly HVAC rooftop plant machinery.

Features and benefits:

Optimal blade pitch of 140 mm ensures superior free area percentages.
Blades can be installed angled either upwards (inverted) or downwards, depending on the desired viewing direction.
Louvres create a seamless, continuous appearance
Complete aluminium build-up for longevity and to meet A2-s1,d0 fire ratings
Blades securely clip in to prevent vandal or theft
Blanking panels can be incorporated to meet acousitc requirements
Integrated single and double door sets are available, or the doors can function as stand-alone components.
Not suitable for weather protection.

General information

Color	Beige Black Blue Bronze Brown Copper Cream Gold Grey Ivory Orange Pink Green Purple Red Silver Turquoise White Yellow Other Show more
Finish	Powder-coated Guidance for specification option: 60 microns. Anodized Guidance for specification option: 25 microns. Manufacturer guidance Blade finish
Material	Aluminium Guidance for specification option: Grade 6063 T6 extruded aluminium.
Shape	Formless Other
Length	3000 mm Manufacturer guidance Louvre blade: 100 mm.
Width	51 mm Manufacturer guidance Louvre blade: 100 mm.
Height	140 mm Manufacturer guidance Louvre blade: 100 mm.
Warranty description	20 year Guidance for specification option: Dependent on specified finish and project location, consult manufacturer.

Uniclass	Ss_25_50_45_45 Louvre screen systemsPrimary
CAWS	L10/54 Louvres L10/650 Metal louvres

Product range	Louvres

Specification data - Louvre screen systems

System performance	30.7% free area. Guidance for specification option: Consult manufacturer for details.
Screen framing	Aluminium louvre frames.
Louvres	-
Type	Aluminium louvre blades. Guidance for specification option: Grade 6063 T6 extruded aluminium.
Operation	Fixed.
Blanking panels	- Manufacturer guidance Consult manufacturer for guidance.
Acoustic panels	-
Facing	- Manufacturer guidance Consult manufacturer for guidance.
Installation fasteners	A2 stainless steel, with bi-metallic corrosion protection.
System accessories	Not required. Insert and vermin mesh. Louvre doors. Blanking panels. Insect mesh. Vermin mesh.

Type	Screening. Manufacturer guidance System type.
Blade pitch	140 mm. Manufacturer guidance Pitch is the distance between the louvres.
Width	51 mm.
Length	3000 mm.
Brackets	Aluminium 6082 T6 and galvanized mild steel. Guidance for specification option: Bracket used is dependent on the fixing details.
Finish	Powder-coated. Guidance for specification option: To 60 μm. Available in RAL/ BS colour from the standard range. Anodized. Guidance for specification option: To 25 μm. Manufacturer guidance Brackets finish.
Mullion	Aluminium 6063 T6 40 mm deep.
Blade support clips	6063 T6 Aluminium.
Vertical support profiles	1225 mm (fixing centres).
Samples required	Consult manufacturer for any samples required.

Sustainability data

Contains Red List materials	No
Country of material origin	Europe
Country of product manufacture	United Kingdom
Material	Aluminium Guidance for specification option: Grade 6063 T6 extruded aluminium.
Recycled content As defined in clause 7.8 of BS EN ISO 14021	95 %
