Render Levelling System

Render Levelling System

F&T Terrix Limited

F&T Terrix is a complete render system suited for restoration projects or new builds. It incorporates polymer silicone technology that ensures longevity of quality and provides a fine smooth finish.

Jump to:
+(44) 333 320 1513 www.ft-terrix.com

Application

  • Polymer-silicate render has all the advantages of the well known silicate renders in the heritage/historical building renovation market but without the limitations related to the application process.
  • It is highly recommended for use in coastal areas where exposure to elements is high.
  • It is suitable for use with most render spray machines and larger projects where the speed of machine application can offer time-saving benefits.
  • Suitable for full application or spot repairs for buildings.

Description

Terrix Render leveling system is a high-performance polymer-silicate system for historical/ housing renovations and new builds due to longevity, fire retardance, zero delamination, and vapor permeability suitable for internal end external use.


Render levelling system components:

  • Terrix® RD-LB base levelling coat.
  • PR-PS-R Primer.
  • RD-PS-S Polymer-Silicate topcoat.


Terrix® RD-LB base levelling coat:

A dry, mineral levelling base coat based on hydraulic adhesives (lime) and aggregates. Ideal for listed buildings or where a very high level of vapour permeability is required.



Terrix® RD-LB Levelling Base Coat can be applied on all typical mineral substrates such as, e.g. concrete, light weight concrete, expanded clay aggregate, ceramic brick and silicate brick as well as porous ceramics. A very high adhesion to porous and absorbent substrates.



PR-PS-R Primer:

  • Enhances render adhesion.
  • Reduces substrate water absorption.
  • Equalises substrate water absorption .
  • Provides high vapour permeability.
  • Reduces risk of algae and fungi growth.


Coloured primer based on low-alkali polymer-silicates and copolymer adhesive intended for proper preparation of substrates for TERRIX® RD-PS and TERRIX® RD-PS-S renders.


Suitable for priming all typical substrates and is designed for external use. Part of TERRIX® EW1, EW2, W1, W2, W3 and EWIR 1 systems. To be applied on mineral substrates (such as concrete, lime render, cement-lime render and cement render) and on substrates covered with well set and bound polymer-based coatings.


RD-PS-S Polymer-Silicate topcoat:

Terrix® RD-PS-S offers all advantages of well know silicate renders without limitations related to the application process (silicate renders are very often used for renovation of historical/listed buildings due to its longevity). Due to its mineral characteristic and lack of surface electrostatics, the product is the most dirt-resistant type of render on the market and will never delaminate as it is adhered to a substrate by a chemical reaction.


Another important property of the render is its built-in high resistance to microbial contamination (eg. algae) as well as efflorescence. Terrix® RD-PS-S 1.5 is recommended for use in coastal areas where exposure to elements is high.


This product would be applied to the facade, after the application of Terrix® AD base coats and adhesives:



Features and benefits to the system:

  • Flame retardant.
  • High resistance to elements.
  • High resistance to dirt.
  • Long lifespan.
  • Low chances of cracking, peeling, or flaking.
  • High chances of colour retention.
  • Resistant to algae and staining.
  • Suitable for spot repairs.
  • Also suitable for winter applications.
  • Full vapour permeability.
  • Low water absorption.
  • Low maintenance cost.
  • Terrix® RD-PS-S 1.5 will never delaminate as it is adhered to a substrate by a chemical reaction.
  • High resistance to microbial contamination (eg. algae) as well as efflorescence.

General information

Color

White

Finish

Grained

1.5 mm.

Material

Polymer

Silicate

Lime

Shape

Formless

Size

Top coat :Single-use plastic bucket contains 20 kg of the product.

WarrantyDescription

Ten year

When installed to manufacturer guidelines.

Uniclass

Ss_25_45_70_55 Multicoat render systemsPrimary

CAWS

M20/19 Proprietary cement gauged render

M20/160 Proprietary cement gauged render

Specification data - Multicoat render systems Enhanced data

System performance

High resistance to elements, dirt and microbial contamination.

First undercoat

RD-LB base levelling coat.

A dry, mineral levelling base coat based on hydraulic adhesives (lime) and aggregates.

Second undercoat

PR-PS-R primer.

Coloured primer based on low-alkali polymer-silicates and copolymer adhesive intended for proper preparation of substrates for TERRIX® RD-PS and TERRIX® RD-PS-S renders.

Final coat

RD-PS-S polymer-silicate topcoat.

Terrix® RD-PS-S offers all advantages of well know silicate renders without limitations related to the application process (silicate renders are very often used for renovation of historical/listed buildings due to its longevity). Due to its mineral characteristic and lack of surface electrostatics, the product is the most dirt-resistant type of render on the market and will never delaminate as it is adhered to a substrate by a chemical reaction.

Packaged weight

20 kg.

Surface finish

Grained, 1.5 mm.

Environmental information

Country of material origin

Germany

Country of product manufacture

Germany

Literature

Terrix® RD-LB -Restoration

Terrix® RD-LB -Restoration

TerrixR RD-PS-S-polymer-silicate-render

TerrixR RD-PS-S-polymer-silicate-render

Terrix PR-PS-R product data sheet

Terrix PR-PS-R product data sheet

Terrix polymer silicate system for new build and restoration properties

Terrix polymer silicate system for new build and restoration properties

Terrix Lime based renovations systems.

Terrix Lime based renovations systems.
