Pocket Door - Sliding Pocket Door System Cavity Walls

Name: Pocket Door - Sliding Pocket Door System Cavity Walls
Brand: P C Henderson Ltd
SKU: qU6g56eTv5e5594yXnWqPd

Verified by manufacturer 23 days ago

PDK3 standard kit

P C Henderson Ltd

Sliding door solution whereby the sliding door disappears into a cavity wall upon opening, offering amazing benefits for environments where space is limited. For wooden doors up to 60 kg.

Jump to:

+44 (0)191 377 7345 Website

Application

Sliding pocket system for wooden doors weighing up to 60 kg.
For internal use.
Suitable for applications where space is limited such as bathrooms, en suites, kitchens, utility rooms, walk-in-wardrobes and disability access areas.

Description

Sliding door solution whereby the sliding door disappears into a cavity wall upon opening, offering amazing benefits for environments where space is limited such as bathrooms, en suites, kitchens, utility rooms, walk in wardrobes and disability access areas.

Features and benefits:

Catering for wooden doors weighing up to 60 kg, Pocket Door is available as a standard kit or with dual soft close to bring the door to a gentle open and close, preventing slamming.
For bi-parting doors, two kits can be used.
Each kit comes with a pre-assembled track and header mechanism, hangers, uprights, clip stop, track stop, guide and round satin flush pull set.
Extremely easy to install
Also available in a more professional and robust version, Pocket Door Pro (specified separately).

Kit components:

Hangers,
Uprights,
Stud insert brackets,
End brackets,
Clip stop and track stop (PDK kits only),
Guide,
Round flush pull set (satin),
Soft close (PDKSOFT kits only)..

General information

Color	Silver
Material	Aluminium
Shape	Rectangle
Width	Bespoke
Warranty description	Ten year

Uniclass	Pr_30_36_36_23 Door track and running gearPrimary
CAWS	P21/10 Door track and running gear P21/350 Door track and running gear

Specification data - Door track and running gear

Standard	To BS EN 1527.
Classification grades (minimum)	-
Durability	Manufacturer's standard.
Door mass	2. Guidance for specification option: Up to 60 kg.
Corrosion resistance	Manufacturer's standard.
Category of door-opening action	1.
Initial friction	Manufacturer's standard.
Form	Manufacturer's standard.
Integral accessories	Track and header assembly; Hangers x2; Uprights x4; Stud insert brackets x2; End brackets x2; Clip stop (601H); Track stop (287); Guide (PD/WRAP); Round flush pull set (satin) (FPR/S).

Length	Manufacturer's standard.
Door leaf	Material: wood. Thickness: 28–44 mm. Maximum door height: 1981 mm. Maximum door width: 762 mm. Maximum weight: 60 kg.
Accessories	None. Simultaneous action kit (SIM100). Guidance for specification option: For bi-parting pocket door applications. Move one door and the other will move simultaneously.

Sustainability data

Contains Red List materials	No
Country of material origin	United Kingdom
Country of product manufacture	United Kingdom
Manufacturing plant location	Bowburn, Durham DH6 5NG, UK
Material	Aluminium
Expected Life	Ten year
