Application

  • Decoration: Conventional applications; furniture, partitions and doors. Products based on Planibel Clearvision – such as painted, acid-etched and sandblasted glass – are suitable for design work.
  • Architecture: For use outdoors as a base glass in architectural applications; laminated (shop windows), double skin facades and coated glass. Even in very thick versions required for wind resistance, Clearvision maintains its first-rate transparency and neutrality.
  • Solar: Suitable for solar applications, photovoltaic solar panels, thermal panels and solar mirrors. It has a particularly high energy transmission and an excellent transmission in the sensitivity spectrums of solar panels, making Planibel Clearvision suitable for maximizing the efficiency of solar applications.

Description

Extra-clear, low-iron float glass.


Features and benefits:

  • Light transmission of 92% (4 mm thick): increases amount of light entering a building, resulting in increased well-being of building occupants.
  • High colour rendering index: Provide superior quality of light in a building and lets the colours of objects or nature seen through the glass appear bright and fresh. When backpainted (interior applications), colours are true and pure.
  • High level of energy transmission.
  • Low level of energy absorption.
  • Even when used in extra-thick version  for furniture or interior design (up to  19 mm), it remains perfectly neutral.

General information

Color

Clear

Material

Glass

Uniclass

Pr_25_71_33_02 Annealed glass sheetsPrimary
Pr_25_71_33_46 Laminated glass sheets
Pr_25_71_33_88 Thermally toughened glass sheets
Pr_25_71_33_37 Heat-strengthened glass sheets

CAWS

L40/380 Bead-fixed insulating glass units – solid bedding, outside bead

L40/450 Single glazing into grooves – sealant capping

H13/115 Structural glass assembly

L10/390 Proprietary windows

H10/10 Patent glazing

L10/31 PVC-U windows

L40/40 Putty-fronted single glazing

L40/50 Bead-fixed single glazing

L40/55 Bead-fixed insulating glass units – drained and ventilated bead

L40/57 Bead-fixed insulating glass units – solid bedding, outside bead

L40/230 Bead-fixed single glazing – non-setting compound

L40/330 Bead-fixed single glazing – capping

L40/350 Bead-fixed single glazing – curing compound and trim

L40/430 Single glazing into grooves – non-setting compound

H10/115 Patent glazing

L10/330 Aluminium windows

L10/20 Steel windows

L40/90 Internal tape glazing

L40/58 Bead-fixed insulating glass units – solid bedding, inside bead

L40/260 Bead-fixed single glazing – extruded gasket

L40/371 Bead-fixed insulating glass units – cellular adhesive/ mastic tape

L40/490 Single-sided gasket glazing

H11/110 Curtain walling

L10/350 PVC-U windows

L10/15 Wood windows

L10/25 Aluminium windows

L10/30 PVC-U windows

L40/250 Bead-fixed single glazing – tape and sealant

L40/310 Bead-fixed single glazing – tape, sealant and trim

L40/370 Bead-fixed insulating glass units – insert gasket sections

L10/210 Wood windows

L10/580 Secondary glazing system

L40/530 Internal tape glazing

L10/10 Wood windows

L10/33 Proprietary windows

L40/210 Putty-fronted single glazing

L40/372 Bead-fixed insulating glass units – loadbearing tapes/ synthetic rubber and sealant capping

L40/381 Bead-fixed insulating glass units – solid bedding, inside bead

L40/410 Single glazing into grooves – extruded rubber/ PVC sections

L10/310 Steel windows

L10/400 Composite windows

L40/470 Zipper gasket glazing

L10/58 Secondary glazing system

Specification data - Annealed glass sheets

General requirements

Glass generally.

Third-party certification

Cradle to Cradle Certified™ Bronze.

Composition

Manufacturer's standard.

Guidance for specification option:

Consult manufacturer for details.

Thickness

3 mm.

Guidance for specification option:

Standard thickness.

Colour rendering index: 100.

Purity: 0.1 (according to CIE 15:2004).

4 mm.

Guidance for specification option:

Standard thickness.

Colour rendering index: 100.

Purity: 0.1 (according to CIE 15:2004).

5 mm.

Guidance for specification option:

Standard thickness.

Colour rendering index: 100.

Purity: 0.1 (according to CIE 15:2004).

6 mm.

Guidance for specification option:

Standard thickness.

Colour rendering index: 100.

Purity: 0.1 (according to CIE 15:2004).

8 mm.

Guidance for specification option:

Standard thickness.

Colour rendering index: 100.

Purity: 0.2 (according to CIE 15:2004).

10 mm.

Guidance for specification option:

Standard thickness.

Colour rendering index: 100.

Purity: 0.2 (according to CIE 15:2004).

12 mm.

Guidance for specification option:

Standard thickness.

Colour rendering index: 99.

Purity: 0.2 (according to CIE 15:2004).

15 mm.

Guidance for specification option:

Non-standard thickness, by request only. Consult manufacturer for details.

19 mm.

Guidance for specification option:

Non-standard thickness, by request only. Consult manufacturer for details.

Body colour

Clear.

Pattern

Guidance for specification option:

Insert requirements where applicable or delete item.

Performance requirements

-

Fire performance

Manufacturer's standard.

Guidance for specification option:

Consult manufacturer for details.

Light

Transmittance: 91–92%.

Guidance for specification option:

Thickness ≤8 mm: 92%; ≥10 mm: 91%.

Thickness 3–8 mm: 92%; 10–12 mm: 91%.

Consult manufacturer for details of thicknesses >12 mm.


Calculated according to EN 410.

Solar control

Solar factor: 89–91%.

Guidance for specification option:

Thickness 3–6 mm: 91%; 8–10 mm: 90%; 12 mm: 89%.

Consult manufacturer for details of thicknesses >12 mm.


Calculated according to EN 410.

Total shading coefficient

Manufacturer's standard.

Guidance for specification option:

Consult manufacturer for details.

Sound attenuation

Manufacturer's standard.

Guidance for specification option:

Consult manufacturer for details.

Impact resistance

Manufacturer's standard.

Guidance for specification option:

Consult manufacturer for details.

Worked finish

-

Method

Not required.

Sandblasted.

Guidance for specification option:

Insert details including design requirements.

Etching.

Guidance for specification option:

Insert details including design requirements.

Applied detail

None.

Silk screen printing and enamelling.

Guidance for specification option:

Insert requirements.

Processing

Not required.

Cutting, straight.

Guidance for specification option:

Insert requirements.

Cutting, circular.

Guidance for specification option:

Insert requirements.

Edge grinding.

Guidance for specification option:

Insert requirements.

Grinding.

Guidance for specification option:

Insert requirements.

Show more

Manufacturer guidance

Consult manufacturer for further details.

Safety

Toughening/ heat strengthening.

Laminating (PVB).

Laminating (EVA).

Glazing units

Not required.

Double glazed IGUs.

Triple glazed IGUs.

Sustainability data

Contains Red List materials

No

Country of material origin

Europe

Country of product manufacture

Europe

Recyclability

Fully recyclable
