PAROC® AST® S

Application

For internal and external walls in normal use in buildings with normal fire requirements.

Description

Fireproof prefabricated stone wool based lightweight sandwich panels. The panels are based on Advanced Structural Technology (AST®) and high-quality PAROC® structural stone wool. The facings are constructed from steel sheet which act together with PAROC structural wool core to provide a composite action of high performance in strength and durability. The bonding between the core and the facings is performed by an adhesive which fully covers the surfaces.

Applications:

For internal and external walls in normal use in buildings with normal fire requirements.

General information

Uniclass 2015

Pr_25_71_14_22 Carbon steel insulating sandwich panelsPrimary

CAWS

H43/10 Metal insulating sandwich panel

H43/120 Metal insulating sandwich panel

Specification data - Carbon steel insulating sandwich panels

Product Reference

PAROC® AST® S

Thickness

80 mm

U-value: 0.48 W/m²K; fire rating: El 30; weight: 17 kg/m².

100 mm

U-value: 0.38 W/m²K; fire rating: El 60; weight: 19 kg/m².

120 mm

U-value: 0.32 W/m²K; fire rating: El 90; weight: 21 kg/m².

150 mm

U-value: 0.26 W/m²K; fire rating: El 180; weight: 23 kg/m².

175 mm

U-value: 0.22 W/m²K; fire rating: El 180; weight: 25 kg/m².

200 mm

U-value: 0.19 W/m²K; fire rating: El 240; weight: 28 kg

240 mm

U-value: 0.16 W/m²K; fire rating: El 240; weight: 32 kg/m².

300 mm

U-value: 0.13 W/m²K; fire rating: El 240; weight: 37 kg/m².

Facing

-

External

-

Profile

Line 150

Line 200

Line 600

Micro

Micro+Line 200

Micro+Line 600

Smooth

Thickness

0.6 mm

Standard.

0.7 mm

Coating

PVDF

For normal exterior use.

PVDF HB

For normal exterior use.

PVDF Matt

For normal exterior use.

Colour

Insert requirement from manufacturer's literature.

Internal

-

Profile

Acoustic – Perforated.

Reface

Line 150

Line 200

Line 600

Smooth

Thickness

0.5 mm

0.6 mm

0.7 mm

Coating

Polyester (SP)

Standard, for interior and external use.

FoodSafe FS-1

Fully food safe for interior use.

FoodSafe FS-2

Food safe for interior use.

Stainless steel (HST)

For special hygiene requirements and premium façades.

Colour

Insert requirement from manufacturer's literature.

Standard product features

Core:

AST® S stone wool, the fibres are uniformly aligned to achieve controlled strength properties. It is specially treated to be water-repellent, non-hygroscopic and non-capillary.

Facing:

Hot dip galvanized coil-coated steel sheet.

Panel length (maximum):

12 m, dependant on panel thickness

Module width:

1200 mm (1196 mm cover width).

Fire classification:

A2-s1, d0.

Sound reduction (Rw):

27–32 dB.

Air tightness (to BS EN 14509, 50 Pa):

<1.0 m³/m²h (sealant in both grooves).

Rain tightness (to BS EN 14509):

1.2 kN/m² (sealant in both grooves).

Product Options

Fixing:

Panels are usually fastened using either penetrating panel fixings or by pressing the panels between profiles.
