PAROC® AST® S+
Prefabricated stone wool based lightweight sandwich panels for walls with high fire requirements.
Application
For walls with high fire requirements.
Description
Fireproof prefabricated stone wool based lightweight sandwich panels. The panels are based on Advanced Structural Technology (AST®) and high-quality PAROC® structural stone wool. The facings are constructed from steel sheet which act together with PAROC structural wool core to provide a composite action of high performance in strength and durability. The bonding between the core and the facings is performed by an adhesive which fully covers the surfaces.
Applications:
For walls with high fire requirements.
General information
Uniclass 2015 | |
CAWS | H43/10 Metal insulating sandwich panel H43/120 Metal insulating sandwich panel |
Specification data - Carbon steel insulating sandwich panels
Product Reference | PAROC® AST® S+ |
Thickness | 100 mmU-value: 0.38 W/m²K; fire rating: El 120; weight: 19 kg/m². 120 mmU-value: 0.32 W/m²K; fire rating: El 120; weight: 21 kg/m². |
Facing | - |
External | - |
Profile | Line 150Line 200Line 600MicroMicro+Line 200Micro+Line 600Smooth |
Thickness | 0.6 mmStandard. 0.7 mm |
Coating | PVDFFor normal exterior use. PVDFFor normal exterior use. PVDF HBFor normal exterior use. PVDF MattFor normal exterior use. |
Colour | Insert requirement from manufacturer's literature. |
Internal | - |
Profile | AcousticPerforated. RefaceLine 150Line 200Line 600Smooth |
Thickness | 0.5 mmStandard. 0.6 mm0.7 mm |
Coating | Polyester (SP)Standard, for interior and external use. FoodSafe FS-1Fully food safe for interior use. FoodSafe FS-2Food safe for interior use. Stainless steel (HST)For special hygiene requirements and premium façades. |
Colour | Insert requirement from manufacturer's literature. |
Standard product features | Core: AST® S+ stone wool, the fibres are uniformly aligned to achieve controlled strength properties. It is specially treated to be water-repellent, non-hygroscopic and non-capillary. Facing: Hot dip galvanized coil-coated steel sheet. Panel length (maximum): 12 m, dependant on panel thickness. Module width: 1200 mm (1196 mm cover width). Fire classification: A2-s1, d0. Sound reduction (Rw): 27–32 dB. Air tightness (to BS EN 14509, 50 Pa): <1.0 m³/m²h (sealant in both grooves). Rain tightness (to BS EN 14509): 1.2 kN/m² (sealant in both grooves). |
Product Options | Fixing: PAROC panels can be installed horizontally, vertically or diagonally. The panels are usually fastened using either penetrating panel fixings or by pressing the panels between profiles. |
