Optitherm Thermostatic Tap With Dual Levers - Clinical Tap Hand Wash/ Decontamination

Name: Optitherm Thermostatic Tap With Dual Levers - Clinical Tap Hand Wash/ Decontamination
Brand: Horne Engineering Ltd
SKU: 3kLRMFaS82gbMaFPseGRPx

Verified by manufacturer 1 month ago

Tap, to suit surgical/sluice trough (+60mm spacer) - TBT1-230DL

Horne Engineering Ltd

Third party certifications:

Type 3 (Healthcare) approved TMV
Certificate type
UK Water Regulation 4
Certificate type

Thermostatic tap for clinical handwash and surgical scrub applications.

Jump to:

BOS

+44 (0)1505 321455 Website

Application

Type 3 TMV and UK Water Regulation 4 Approved Thermostatic lever tap for healthcare, clinical and surgical scrub applications.

Description

A bib-mounted dual lever, thermostatic tap with integral mixing valve, warm and cold water delivery for use in healthcare and clinical applications.

Features and benefits:

Integral Type 3 (healthcare) approved thermostatic mixing valve complete with easy-access isolation valves, check valves, strainers and thermostatic cartridge.
Robust, reliable design ensures optimum performance over extended lifetime.
Safe, consistent and comfortable warm water delivery aids hand hygiene compliance.
Integral combined flow regulator-conditioner (6 L/min) at outlet for water economy without splashing.
Dual lever operation - elbow shut off avoids hand recontamination after washing.
Clutch mechanism on levers prevents accidental or intentional breakage.
Safe surface temperature (≤42°C) ensured during and after operation.
Cold water bypass for dedicated cold water delivery.
Pressure tested assembly.

Required Accessory

Spigot flushing boot, P/N 5684 - facilitates compliant commissioning in accordance with BS 806-4 & BS 8558.

Recommended Accessories

Flushing Kit, P/N 5492
Strap Wrench, P/N 5457
Multi-tool, P/N 5459
Cartridge removal tool, P/N 20-5458
Universal cache key, P/N 44-6667
12mm hex key
4mm hex key
Torx T20 key

Optional Accessories

Full toolkit for Optitherm, P/N 5491 (includes all recommended accessories).

General information

Color	Silver
Finish	Chrome
Material	Brass Zinc Copper Plastic Polymer Stainless steel Show more
Shape	Other
Length	180 mm Guidance for specification option: from wall surface to point of water discharge (TBT1-170DL variant) 210 mm Guidance for specification option: from wall surface to point of water discharge (TBT1-200DL variant) 240 mm Guidance for specification option: from wall surface to point of water discharge (TBT1-230DL variant)
Width	194 mm
Height	238 mm
Warranty description	Two year Guidance for specification option: Warranty only applies to materials and workmanship. Does not cover inappropriate handling, incorrect installation, commissioning, operation or maintenance (or lack of). www.horne.co.uk/contact-us/customer-services/the-horne-guarantee/

Uniclass	Pr_40_20_87_87 Thermostatic mixer tapsPrimary Pr_40_20_87_50 Lever-action bib taps Pr_40_20_87_94 Wall-mounted lever-action bib taps Pr_40_20_87_93 Wall-mounted bib taps
CAWS	N13/362 Bib taps N13/346 Washing troughs N13/335 Washbasins N13/30 Washbasins N13/24 Bib taps:

Specification data - Thermostatic mixer taps

Standards	In accordance with HTM 04-01: Safe water in healthcare premises, HTM Performance specification D 08 and BS 7942.
Approvals	Type 3 TMV and UK Water Regulation 4 Approval.
Form	Thermostatic mixer taps.
Materials	-
Body	Brass.
Finish and colour	Chrome-plated.
Flow rate (maximum)	6 L/minute.
Water supply temperature (maximum)	41°C. Guidance for specification option: Pre-set maximum outlet temperature 41°C (with 1°C margin). Range of temperature adjustment 35–44°C. Hot water supply temperature: 55–65°C.
Integral accessories	60 mm spacer.

Water pressure	Maximum static pressure: 10 bar. Range of maintained water supply pressures: 1–5 bar.
Connections	Hot and cold, 10 mm compression, via mounting spigot.
Accessories	Spigot flushing boot, P/N 5684. Guidance for specification option: Required accessory facilitates compliance with BS 806-4 and BS 8558 (installation and commissioning). Flushing Kit, P/N 5492. Guidance for specification option: Alternative kit for flushing water supplies with the tap in-situ. As Spigot flushing boot above, facilitates a cleansing flush at commissioning but also for regular removal of pipework biofilm to maintain system water quality. Strap Wrench, P/N 5457. Multi-tool, P/N 5459. Cartridge removal tool, P/N 20-5458. Universal cache key, P/N 44-6667. 12 mm hex key. 4 mm hex key. Torx T20 key. Full toolkit for Optitherm, P/N 5491. Guidance for specification option: Optional accessory. Includes all recommended accessories. Show more Manufacturer guidance All of the accessories are recommended unless noted otherwise.

Sustainability data

Country of product manufacture	United Kingdom
Material	Brass Zinc Copper Plastic Polymer Stainless steel Show more
Recyclability	Recyclable (where facilities exist)
