Optima® XPC 200 mm (Extruded Plank Rainscreen)

Third party certifications:

QA Certificate
Certificate type

Optima® XPC 200 mm-wide extruded aluminium plank rainscreen cladding system.

Jump to:

+44 (0)191 587 2287 www.sotech-optima.co.uk

Application

Robust design can be secret-fixed horizontally, vertically or diagonally.

Description

Robust secret-fix extruded aluminium plank system based around 200 mm-wide planks. Comprises a 6063 T6 extruded plank panel, XPC carrier rails 'T&L' and adjustable helping hands brackets.

Features and benefits:

Adjustable brackets.
Also available in different standard widths: 150 mm, 225 mm and 250 mm (specified separately).
Recessed or hairline appearance.
Seamless integration.
CWCT-certified and approved.
Compliant to NHBC requirements.

Consult the manufacturer to discuss bespoke detail proposals.

General information

Finish	Anodized Powder-coated
Material	Aluminium
Shape	Rectangle
Width	Bespoke mm
Height	Bespoke mm
WarrantyDescription Dependent on specified finish and location, consult manufacturer.	-

Uniclass	Ss_25_20_70_25 Drained and back-ventilated rainscreen cladding systemsPrimary
CAWS	H92/120 Rainscreen cladding

Specification data - Drained and back-ventilated rainscreen cladding systems Enhanced data

System performance Insert requirements.	-
Thermal insulation Insert requirements or omit.	-
Breather membrane	-
Material Insert requirements or omit.	-
Fasteners Insert requirements or omit.	-
Secondary support structure Consult manufacturer for further details.	XPC carrier rails 'T&L' and adjustable helping hands brackets.
Cavity fire barriers	-
Horizontal Insert requirements or omit.	-
Vertical Insert requirements or omit.	-
Cladding panels	-
Material Planks are 15 mm-deep (2.5 mm thick), and available up to 6400 mm long. Insert requirements or other details e.g. drawing reference or schedule.	200 mm-wide 6063 T6 aluminium, anodized. Insert colour requirements. 200 mm-wide 6063 T6 aluminium, polyester powder-coated. Insert colour requirements.
Panel joints The aluminium planks are connected by a simple interlocking male/female joint, which offers either a recessed or hairline appearance. Consult manufacturer for further details.	Recessed. Hairline.
Reveals Insert requirements or omit.	-
Samples required Insert requirements or omit.	-
