Novia® Black+ Construction Wrap Light Wall Breather - Lightweight Breather Membrane

Name: Novia® Black+ Construction Wrap Light Wall Breather - Lightweight Breather Membrane
Brand: Novia Ltd
SKU: vWAwUdzzYrWCj3FZDbLhHe

Verified by manufacturer 24 hours ago

Novia Ltd

It is a lightweight 3-layer high performance wall breather membrane with W1 water penetration rating and excellent breathability in a large oversized roll.

Jump to:

Request BIM

01795 515 110 Website

Application

Suitable for all insulated frame applications, light steel frame, SFS and timber frame.

Description

Novia® Black+ Construction Wrap Light achieves EN 1928 W1 water penetration resistance while remaining highly breathable. Novia® Black+ Construction Wrap Light is a wall breather. It is a Lightweight 3-layer, high performance wall breather membrane designed for use in all insulated wall applications. It also complies with EN 13501-1 Fire Classification E.

The large roll size makes it easy for external wall insulated frames to be wrapped and watertight in a short period of time. Equally the large roll size makes it easy to utilize on a production line ensuring fast and simple panel manufacture.

Novia® Black+ Construction Wrap Light is black on one side and grey on the reverse. There are no text, logos or images on either side.

Novia® Black+ Construction Wrap Light is compliant with mandatory UKCA marking requirements for use as a wall breather membrane and can be used in pitched roof applications too.

Features and benefits:

Water penetration resistance to EN 1928 W1 Class.
2.7 m wide material for fast coverage and installation.
Class E (fire) to EN 13501-1.
Low cost, Light weight, W1 wall breather membrane.
UKCA certified to EN 13859-1 for (roofs) and EN 13859-2 for (walls).
Good tensile and nail tear strength.
Recyclable and ecologically harmless.
Provides temporary protection during the construction phase.

General information

Color	Black Grey
Finish	Embossed
Material	Polypropylene
Shape	Other Guidance for specification option: Roll.
Length	100000 mm
Width	2700 mm
Warranty description	Lifetime

Uniclass	Pr_25_57_10_94 Vapour-permeable sheetsPrimary
CAWS	H22/130 Breather membrane H30/350 Breather membrane H92/785 Breather membrane P10/320 Breather membrane H21/20 Breather membrane H30/50 Breather membrane H31/55 Breather membrane P10/65 Breather membrane H21/130 Breather membrane H31/280 Breather membrane

Specification data - Vapour-permeable sheets

Classification data
Standard	To BS EN 13859-1 and EN 13859-2. Guidance for specification option: UKCA / CE compliant to EN 13859-1 (roofs) and EN 13859-2 (walls).
Class (minimum)	W1.
Third-party certification	UKCA compliant.
Performance criteria	-
Water vapour properties	Guidance for specification option: (After ageing W1).
Material	Polypropylene.
Form	Embossed.
Weight (minimum)	92 g/m². Guidance for specification option: (Roll weight: 28 kg to EN 1849-2). Manufacturer guidance Nominal weight to EN 1849-2.
Width	2.7 m. Manufacturer guidance Standard.
Length	100 mm. Manufacturer guidance Roll length.
Tensile strength	To EN 12311-1, 250 N/50 mm (MD); 125 N/50 mm (CD).
Elongation	To EN 12311-1, 65% (MD); 70% (CD).
Resistance to tearing	To EN 12310-1, 75 N (MD); 80 N (CD).
Sd value	To EN ISO 12572, 0.029 m.
Low temperature stability	To EN 1109, - 60°C.
Reaction to fire	To EN 11925-2, Class E.
UV resistance	1 month.
Colour	Black.

Sustainability data

Contains Red List materials	No
Country of material origin	United Kingdom
Country of product manufacture	United Kingdom
Material	Polypropylene
Recyclability	N/A
Recycled content As defined in clause 7.8 of BS EN ISO 14021	0 %
Expected Life	Lifetime
