MRA PAS68 HVM Manual Security Barrier
Verified by manufacturer 5 months ago
3 m MRA PAS 68 Crash Rated Manual Barrier MK3
3 m MRA PAS 68 Crash Rated Manual Barrier MK3
Crash rated manual barrier, tested to PAS68.
Application
Designed specifically to stop vehicles gaining access to sites of Critical National Infrastructure (CNI), including:
- Industrial.
- Infrastructure.
- Utilities.
- Construction.
Description
Crash rated, manually operated rising and drop arm barrier. Tested to PAS68, and designed to be incorporated into Zaun's range of perimeter protection systems.
Features and benefits:
- Designed to combat differing speeds and vehicle types to suit most site requirements.
- Three lengths available to deal with various threat levels, with a maximum length of 4500 mm.
- Rising beam is fully welded using a steel frame.
- An impact beam is fitted.
- No power required.
- Additional signage, warning and information signs are available.
- Secured by Design.
PAS68 ratings:
- 3 m MRA PAS 68 Crash Rated Manual Barrier MK3: V3500/80/90/2.2-0.0.
- 4 m MRA PAS 68 Crash Rated Manual Barrier MK2: V7500/48/90/0.0-0.0.
- 4.5 m MRA PAS 68 Crash Rated Manual Barrier MK3: V7500/48/90:0.0/0.0.
Consult manufacturer for further information.
General information
Shape | Rectangle |
Color | Yellow |
Material | Metal |
Size | 1000 x 1800 x 500 mm Guidance for specification option: L x W x D Manufacturer guidanceCivil requirements. |
Uniclass | |
CAWS | Q41/190 Vehicle access point barriers |
Specification data - Rising arm vehicular barriers
Standard | To BS1722, ISO 12944, PAS 68. |
Method of operation | Manual. |
Arms | |
Type | Counterbalanced barrier. |
Finish as delivered | |
Colour | Manufacturer guidanceInsert RAL colour requirement. |
Accessories | Not required.Signage.Guidance for specification option: For information. Warning signs. |
Rating | PAS68:2010 V3500/80/90/2.2-0.0. Guidance for specification option: Capable of stopping a vehicle at 50 mph. |
Beam length | 3000 mm. |
Height | 900 mm. Manufacturer guidanceBeam height. |
Literature
Perimeter Hostile Vehicle Mitigation HVM PAS 68
