Moralt Laminesse FireSmoke 54 mm PEFC® - Door Blank
Verified by manufacturer 1 month ago
High-performance timber internal/ external door blank.
Application
Suitable for internal and external doors.
Description
54 mm thick, high-performance, PEFC® certified timber internal/ external door blank with a 6 mm thick MDF facing (includes feature grooves up to 6 x 4 mm).
Features and benefits:
- Certified single/ double leaf with and without vision panels.
- Laminated core from peeled veneers with vertically aligned annual rings.
- Lightweight, yet strong and stable.
- Cut-to-size panels.
- Good stability and durability ratings.
- Suitable for veneering and laminating.
- FD60 fire rating in accordance with BS 476-22.
- 35/ 36 dB flush, 37 dB glazed sound reduction performance in accordance with BS EN ISO 140-3.
General information
Color | Brown |
Material | Medium density fibreboard (MDF) Wood |
Shape | Rectangle |
Width | 2700 mm Guidance for specification option: Maximum. Bespoke Guidance for specification option: Cut to size. Contact manufacturer for details. |
Height | 5200 mm Guidance for specification option: Maximum. Bespoke Guidance for specification option: Cut to size. Contact manufacturer for details. |
Uniclass | |
CAWS | L20/20 Wood flush doors L20/230 Wood flush doors |
Product range |
Specification data - Wood flush door leaves
Format | Single leaf.Double leaf. |
Thickness | 54 mm. |
Door leaf size | 5200 x 2070 mm.Guidance for specification option: Maximum size. 4200 x 1830 mm.Guidance for specification option: Stock size. |
Performance | |
Fire resistance | |
Insulation | To BS 476-22, 30 minutes.To BS 476-22, 60 minutes. |
Acoustic performance | To BS EN ISO 140-3, 35/ 36 dB (flush); 37 dB (glazed). |
Thermal | 1.71 W/m²K. |
Door structure | Laminated core from peeled veneers with vertically aligned annual rings. |
Facings | Medium density fibreboard (6 mm).Guidance for specification option: Feature grooves up to 6 x 4 mm. Contact manufacturer for details. Other.Guidance for specification option: Facings supplied by Yeoman Shield and CS Group Acrovyn, consult manufacturer and insert requirements. |
Hardware | Guidance for specification option: Safehinge hardware available, consult manufacturer and insert requirements. |
Colour | |
External | Brown. |
Internal | As External. |
Accessories | Not required.Vision panels. |
Weight | 30 kg/m². |
