Description

Creates a stylish and strong washroom environment offering tasteful design with profiles pilasters and elegantly-concealed floor fixings.

Specification data
Product Reference

Modelle Glass

10 mm ceramic baked toughened float glass, silk screen printed in twelve RAL colours.

Modelle SGL

12.5 mm solid grade laminate.

Modelle HPL

18 mm high grade particle board 650 kg/m³ with high pressure laminate. 20 mm overall panel thickness.

Colour/ Finish -
Division

Refer to Maxwood colour selector

Doors

Refer to Maxwood colour selector

Over door panel

Not applicable

Refer to Maxwood colour selector

Pilasters

Refer to Maxwood colour selector

Glass

Not applicable

Frosted

Listral (rough textured)

Satin

Silk screen printed RAL

Refer to Maxwood colour selector

Standard product features

Size:

  • Overall height: 1900mm including 100 mm clearance.
  • Division (h x w): 1800 x 1500–1800 mm.
  • Door: 1800 mm high.
  • Centre pilaster: 1800 x 200 mm.
  • End pilaster (h x w): 1800 x 100 mm.

Dividers and doors:

- Edge treatment:

  • Modelle Glass: All edges softened and polished.
  • Modelle SGL: All edges radiused and polished, with rounded corners.
  • Modelle HPL: All edges lipped in impact-resistant ABS with polyurethane adhesive. All components are bonded with specialist polyurethane washroom adhesive, for ultimate water-resistant strength of bonding, environmentally friendly it's zero rating on formaldehyde emissions

Headrail:

Bullnosed aluminium headrail corresponding to profiled pilasters.

Pilasters:

Profiled extruded aluminium with internal webs for maximum strength and durability, complete with 50 mm aluminium skirt to base of pilaster.

- Colour/ Finish:

Powder coated in a range of 11 textured finishes. Other RAL colours available on request.

Ironmongery:

  • Indicator bolt: 'Orb' range DDA-compliant highly-visible indicator with emergency release.
  • Division fixing: Continuous aluminium channel with bolt-through fixings.
  • Hinges: Very robust aluminium fall-to-close hinges.
