Mezzo Toilet Cubicles
Verified by manufacturer 3 months ago
Toilet cubicles available in a range of materials.
Application
Public washrooms.
Description
Toilet cubicles available in particleboard, laminate, veneer, glass and cast acrylic.
Headrail:
- Satin anodized aluminium aerofoil profile to match pilasters.
Glass doors (MezzoG):
- Doors and partitions: 10 mm toughened and screen printed safety glass.
Glass doors with laminate partitions (MezzoGhpl):
- Doors: 10 mm toughened and screen printed safety glass.
- Partitions: 18 mm MR MDF faced on both sided with high pressure laminate (HPL).
Glass doors with solid grade laminate partitions (MezzoGsgl):
- Doors: 10 mm toughened and screen printed safety glass.
- Partitions: 12/ 13 mm solid grade laminate (SGL).
Glass doors and real wood veneer partitions (MezzoGv):
- Doors: 10 mm toughened and screen printed safety glass.
- Partitions: 18 mm MR MDF faced on both sided with real wood veneer.
Laminate doors (MezzoHPL):
- Doors and partitions: 18 mm MR MDF faced on both sides with high pressure laminate (HPL).
MFC doors (MezzoMFC):
- Doors and partitions: 19 mm moisture resistance (MR) melamine faced chipboard (MFC).
Solid grade laminate doors (MezzoSGL):
- Doors and partitions: 12/ 13 mm solid grade laminate (SGL).
Real wood veneer doors (MezzoV):
- Doors and partitions: 18 mm MR MDF faced on both sides with real wood veneer.
General information
Material | Glass High pressure laminate (HPL) Solid grade laminate (SGL) Melamine |
Size | Manufacturer guidance
|
Width | 1500 mm 1800 mm Manufacturer guidance1500–1800 mm. |
Height | 1950 mm |
Warranty description | One year Guidance for specification option: From practical completion. |
Uniclass | |
CAWS | K32/10 Panel cubicles K32/120 Panel cubicles |
Product range |
Specification data - Panel cubicle systems
Panels | Melamine faced particleboard (MFC).High pressure laminate (HPL).Solid grade laminate (SGL).Veneer.Glass.Manufacturer guidanceAvailable in a choice of materials including MFC, HPL, solid grade laminate (SGL), veneer and glass. |
Panel supports | Satin anodized aluminium pedestal legs. |
Pilasters | Satin anodized aluminium (curved) aerofoil section (and headrail). |
Doors | Melamine faced particleboard (MFC).High pressure laminate (HPL).Solid grade laminate (SGL).Veneer.Glass.Manufacturer guidanceAvailable in a choice of materials including MFC, HPL, solid grade laminate (SGL), veneer and glass. |
Lippings | Manufacturer guidanceEdge treatment:
|
Hardware | Stainless steel 4 inch butt hinges.Full length channels.Coat hook.Easily operable cast plastic indicator bolt. |
System accessories | Stainless steel pull handle.Grab rails.Handrail.Manufacturer guidanceCubicles are available in configurations to comply with Approved Document M (E&W), complete with outward opening doors. A standard stainless steel pull handle is supplied to the outside face of all outward opening cubicle doors. Complementary grab rails and hand rail are also available. |
Product Reference | Mezzo Toilet Cubicles |
Type | MezzoG. Guidance for specification option: Glass doors. MezzoGhpl. Guidance for specification option: Glass doors with laminate partitions. MezzoGsgl. Guidance for specification option: Glass doors with solid grade laminate partitions. MezzoGv. Guidance for specification option: Glass doors and real wood veneer partitions. MezzoHPL. Guidance for specification option: Laminate doors. |
Pilaster finish | Manufacturer guidanceSplit pairs of elliptical/ aerofoil aluminium pilasters 200 x 40 mm. Satin anodized as standard. Other finishes available upon request subject to surcharge. |
Legs | Not required Required Manufacturer guidanceTwo options available:
|
Sustainability data
Country of material origin | United Kingdom |
