Forte Changing Cubicles - Changing Cubicles

Name: Forte Changing Cubicles - Changing Cubicles
Brand: Washroom Washroom Ltd
SKU: n3gWKUJed6xVB6E7tCQVsx

Verified by manufacturer today

Panel changing cubicle with integral benches and anti peep slats.

Jump to:

Application

Suitable for public changing areas, end of trip

Solid grade laminate (SGL) panel changing cubicles with integral benches and anti peep slats.

Features and benefits:

Integrated bench seating.
Manufactured from 12/ 13 mm solid grade laminate.
Wear and water resistant solution in a wide range of colours.
D-shaped satin anodized aluminium headrail.
Stainless steel butt-hinges, full length SAA channel, pilaster fixings, buffered coat hook, and nylon and stainless steel indicator bolt.

Color	Other Manufacturer guidance To be confirmed from WW standard SGL range, subject to depth of partition.
Finish	Satin Powder-coated Anodized
Material	Solid grade laminate (SGL)
Shape	Rectangle
Length	Bespoke
Width	- Manufacturer guidance As per drawings.
Height	1950 mm
Warranty description	One year Guidance for specification option: From practical completion.

Uniclass	Ss_25_12_60_60 Panel cubicle systemsPrimary
CAWS	K32/10 Panel cubicles K32/120 Panel cubicles

Product range	Forté

Classification data
Panels	12/ 13 mm solid grade laminate (SGL). Manufacturer guidance A wide range of laminates available, please contact manufacturer for details.
Panel supports	Satin anodized aluminium pedestal legs.
Pilasters	12/ 13 mm solid grade laminate (SGL). Manufacturer guidance A wide range of laminates available, please contact manufacturer for details.
Doors	12/ 13 mm solid grade laminate (SGL). Manufacturer guidance A wide range of laminates available, please contact manufacturer for details.
Lippings	Exposed edges machined to a smooth finish with radiused safety corner details to doors and pilasters.
Hardware	Stainless steel 4 inch butt hinges. Full length SAA channel cleats. Buffered coat hook. Easily operable indicator bolt.
Legs	Tubular and rounded off design manufactured from satin anodized aluminium, fixed to partition panel. Adjustable to suit uneven floor levels.
Seating	300 mm plank seat, 12/13 mm SGL.
Other requirements	Where indicated on drawings supplied, outward opening doors have been allowed complete with satin polished stainless steel pull handles to the outside face of the doors.
Colour	- Manufacturer guidance To be confirmed from WW standard SGL range, subject to depth of partition.
Colour/ Finish	Satin, anodized. Polyester powder-coated. Guidance for specification option: Any RAL colour in semi-gloss, insert requirements. Manufacturer guidance Fixings colour and finish.
