Double glazing, iplus Top 1.1 on Clearlite
Double glazing, iplus Top 1.1 on Clearlite
Range of low-emissivity products dedicated to thermal insulation, providing a more comfortable living space.
Application
Residential buildings and homes.
Description
Range of low-emissivity products dedicated to thermal insulation, providing a more comfortable living space.
Features and benefits:
- Can be used in double or triple glazing, in standard or toughened versions (requiring tempering).
- Cradle to Cradle Certified™ Silver.
- Selected products carry the PassivHaus Certified Component label when assembled in triple glazing.
- Solutions available for a range of needs: cover protection from the cold; achieving both thermal insulation and solar control; good insulation while preventing condensation or additional safety functions.
- Easy to process: durable surface resists scratches and handling.
iplus Top 1.1/ iplus Top 1.1T (on Clearlite):
- Very high solar factor.
- High light transmission.
- Good thermal insulation.
iplus Advanced 1.0/ iplus Advanced 1.0T (on Clearlite):
- Enhanced thermal insulation.
- High light transmission.
Other options (consult manufacturer for details):
- iplus LS/ iplus LST: Triple glazed with a high solar factor .
- iplus Energy N/ iplus Energy NT: Offers a high level of solar protection.
- iplus AF/ iplus AF Top/ iplus Energy N: Pyrolytic coating to prevent the formation of condensation.
General information
Color | Clear |
Material | Glass |
Shape | Rectangle |
Length | Bespoke |
Width | Bespoke |
Height | 24 mm 40 mm |
Uniclass | |
CAWS | H10/10 Patent glazing H10/115 Patent glazing H11/110 Curtain walling H13/115 Structural glass assembly L10/10 Wood windows L10/15 Wood windows L10/20 Steel windows L10/210 Wood windows L10/25 Aluminium windows L10/3 PVC-U windows L10/31 PVC-U windows L10/310 Steel windows L10/33 Proprietary windows L10/330 Aluminium windows L10/350 PVC-U windows L10/390 Proprietary windows L10/400 Composite windows L10/58 Secondary glazing system L10/580 Secondary glazing systems L40/210 Putty-fronted single glazing L40/230 Bead-fixed single glazing – non-setting compound L40/250 Bead-fixed single glazing – tape and sealant L40/260 Bead-fixed single glazing – extruded gasket L40/310 Bead-fixed single glazing – tape, sealant and trim L40/330 Bead-fixed single glazing – capping L40/350 Bead-fixed single glazing – curing compound and trim L40/370 Bead-fixed insulating glass units – insert gasket sections L40/371 Bead-fixed insulating glass units – cellular adhesive/ mastic tape L40/372 Bead-fixed insulating glass units – loadbearing tapes/ synthetic rubber and sealant capping L40/380 Bead-fixed insulating glass units – solid bedding, outside bead L40/381 Bead-fixed insulating glass units – solid bedding, inside bead L40/40 Putty-fronted single glazing L40/410 Single glazing into grooves – extruded rubber/ PVC sections L40/430 Single glazing into grooves – non-setting compound L40/450 Single glazing into grooves – sealant capping L40/470 Zipper gasket glazing L40/490 Single-sided gasket glazing L40/50 Bead-fixed single glazing L40/530 Internal tape glazing L40/55 Bead-fixed insulating glass units – drained and ventilated bead L40/57 Bead-fixed insulating glass units – solid bedding, outside bead L40/58 Bead-fixed insulating glass units – solid bedding, inside bead L40/90 Internal tape glazing |
Specification data - Thermally toughened glass sheets
Classification data | |
General requirements | Glass generally. |
Third-party certification | Cradle to Cradle Certified™ Silver. |
Composition | Manufacturer's standard. |
Toughening process | Not required. |
Thickness | 24 mm. |
Body colour | Clear (Clearlite). Manufacturer guidanceExternal appearance will vary based on which glazing combination is specified; consult manufacturer's literature for details. |
Coating | |
Type | iplus Top 1.1. Guidance for specification option: Coating position: 3. |
Performance requirements | |
Fire performance | Manufacturer's standard. Guidance for specification option: Consult manufacturer for details. |
Light | Transmission: 82%; reflection: 12%. |
Solar control | Solar factor: 64%. |
Total shading coefficient | Manufacturer's standard. Guidance for specification option: Consult manufacturer for details. |
Thermal insulation | Manufacturer's standard. Guidance for specification option: Consult manufacturer for details. |
Sound attenuation | Manufacturer's standard. Guidance for specification option: Consult manufacturer for details. |
Impact resistance | Manufacturer's standard. Guidance for specification option: Consult manufacturer for details. |
Thermal transmittance (U-Value) | 1.1 W/m²K. |
Configuration | Double glazing. Guidance for specification option: 4-16-4, Argon: 90%. |
Literature
iPlus, Glass for Insulation
