ImpactPRO® iDigital PVC Hygienic Wall Cladding
Verified by manufacturer 2 months ago
Gloss Finish
Gloss Finish
BS EN 13501-1
Certificate type
Extruded semi-rigid PVC sheet offering combined benefits of uPVC fire rated material with high-resolution digitally printed images and a UV cured clear hard coating.
Application
Suitable for hygienic applications such as:
- Hotels.
- Retail.
- Restaurants.
- Kitchens.
- Bathrooms.
- Leisure Facilities.
- Healthcare.
- All hygienic and hard wearing applications.
Suitable substrates:
- 12.5 mm thick plasterboard.
- OSB Board 12 mm.
- Minimum 9 mm W.P.B resin bonded to substrate.
(PVA sealer not generally required).
All these surfaces will require PVA sealer coat by others unless specified otherwise.
- Good quality fair faced brick or block work. Well aligned joints bagged up flush.
- Straight to within 3 mm over a 2 m straight edge and bricks/ blocks flush with one's adjacent.
- Sand and cement rendering 1:3 to a steel trowel finish.
- Ceramic tiles which are securely bonded to substrate. (No responsibility is accepted for any subsequent delamination of tiles from the substrate).
- Pre-cast concrete walls (must have PVA sealer coat).
- Certain sound painted surfaces (an adhesive test is advisable to ascertain compatibility).
- Plastered surfaces (subject to survey by Installer to confirm suitability).
NB: Pink lightweight plasters are generally not suitable.
Painted surfaces will require a 'key' to avoid delaminating of paint from substrate.
Description
ImpactPRO iDigital 2.5 mm Hygienic Cladding Solid PVC Sheet. 2.5 mm for uneven walls with imperfections, for example covering over tiles which have been removed or uneven brick/blockwork.
This distinct range of decorative hygienic wall cladding combines the benefits of uPVC fire rated material with high-resolution digitally printed images and a UV cured clear hard coating.
Features and benefits:
- ImpactPRO iDigital - high= quality PVC sheet.
- 2.5 mm solid PVC hygienic cladding sheet.
- Food grade, high chemical resistance.
- Class 0 fire rating.
- High impact resistant.
- Matching profile trims available.
- Bespoke wall designs.
- High abrasion and chemical resistance.
- Clear transparent high gloss or matt finish.
- Durable, enhancing the life of uPVC substrate.
- Good temperature range (+60 to -0°C).
- Effective hygienic wall protection.
- Easy to install.
General information
Color | Other |
Finish | Gloss Matt |
Material | PVC |
Shape | Rectangle |
Length | 2440 mm 2800 mm 3050 mm |
Width | 1220 mm |
Height | 2.5 mm |
Warranty description | 20 year |
Uniclass | |
CAWS | K13/145 Proprietary plastics cladding K13/145 Proprietary plastics cladding |
Specification data - Plastics sheet wall claddings
Material | Solid PVC sheet. |
Thickness | 2.5 mm. |
Sheet size | 2440 x 1220 mm.2800 x 1220 mm.3050 x 1220 mm. |
Finish | Gloss. |
Colour | White metro tile.Black marble tile.White marble.Grey marble. |
Edges | Manufacturer guidanceMatching profile trims available. Consult manufacturer and insert requirements. |
Fire performance | To BS 476-Part 6, V-0. |
Specific gravity | To DIN ISO 1183, 1.45 g/cm³. |
Water absorption | To EN ISO 62, 0.20%. Manufacturer guidanceWater absorption till saturation 23°C. |
Service temperature range | 0–60℃. |
Tensile strength | To DIN EN ISO 527-1, >45 MPa. |
Elongation | To EN ISO 527, >45%. |
Shore Hardness - D | To DIN EN ISO 868, 68. |
Modulus of elasticity | To ISO 527-1,2, >2500 MPa. |
Softening temperature | To DIN EN ISO 306, 70°C. Manufacturer guidanceVicat-softening point VST/B/50. |
Coefficient of thermal expansion | To DIN 53752, 0.7 m/(m.K). Manufacturer guidanceCoefficient of linear thermal expansion 23°C–100°C. |
Thermal conductivity (maximum) | To DIN 52612, 0.2 W/mK. Manufacturer guidanceAt 23°C. |
Vapour resistivity | To DIN 53482, 10^13 Ω. |
Strength | To MSZ EN 60243-1, 18 kV/mm. Manufacturer guidanceDielectric strength. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Hungary |
Country of product manufacture | United Kingdom |
Material | PVC |
Manufacturing plant location | |
Recyclability | 100% Guidance for specification option: The recyclability is 100% given for Trovidur® EC-Clad, as long as the protective film is removed and the material is free from contamination like adhesive residues. |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 100 % |
Expected Life | 20 year |
Third party certifications
BS EN 13501-1
ImpactPRO Fire Certification
Literature
ImpactPRO® Cladding Collection Colour Guide
ImpactPRO® iDigital Collection
ImpactPRO® Installation Guide
ImpactPRO® Technical Properties Data Sheet
ImpactPRO® uPVC Cladding Sheet Technical Data
