Hudevad Niveau Vertical - Radiator

Verified by manufacturer 2 months ago

Type 11 Radiator

Hudevad Radiator Design A/S Variant:

Wall-mounted vertical radiator.

Jump to:
+44 (0)24 7688 1200 Website

Application

Suitable for the interior of any room. Can be used in all commercial settings, office spaces and also private homes where a robust and effective radiator is needed.

Description

A vertical radiator, suitable for any environment and build. It has a smooth front plate and closed sides, and is suitable for spaces where space is limited or where extra heat output is needed.


Features and benefits:

  • Simplistic design.
  • Available in three different types.
  • Wall mounted.
  • Ten-year warranty.

General information

Color

White

Guidance for specification option:

White RAL 9016, gloss 70.

Other

Finish

Powder-coated

Material

Steel

Shape

Rectangle

Length

300 mm

400 mm

500 mm

600 mm

700 mm

Width

49 mm

79 mm

102 mm

Height

1600 mm

1800 mm

2000 mm

2200 mm

Warranty description

Ten year

Uniclass

Pr_70_60_36_73 RadiatorsPrimary

CAWS

T90/465 Radiators

T90/465 Radiators

Specification data - Radiators

Standards

To BS EN 442-1 and BS EN 442-2.

Radiator type

Single convector panel.

Output

Guidance for specification option:

Consult manufacturer's literature and insert requirements.

Finish

Powder-coated.

Connections

Guidance for specification option:

All connections 1/2” standard (adapters available).

Accessories

T1180 Floor support.

Danfoss RA-N valve.

Not required.

Heating element

To BS EN 442, steel panel.

Colour

White RAL 9016, gloss 70.

Guidance for specification option:

Standard.

Other.

Guidance for specification option:

Can be painted in other colours. Insert requirements.

TestPressure

13 bar.

Operating pressure (maximum)

To BS EN 442, 10 bar.

Operating temperature

110°C.

Height

1600 mm.

Guidance for specification option:

  • Water content: 7.2 L/m.
  • Weight: 56.30 kg.

1800 mm.

Guidance for specification option:

  • Water content: 8.1 L/m.
  • Weight: 63.00 kg.

2000 mm.

Guidance for specification option:

  • Water content: 9.0 L/m.
  • Weight: 69.6 kg.

2200 mm.

Guidance for specification option:

  • Water content: 9.8 L/m.
  • Weight: 75.6 kg.

Manufacturer guidance

Consult manufacturer's literature for details.

Width

300–700 mm.

Guidance for specification option:

In increments of 100 mm.

Consult manufacturer's literature and insert requirements.

Manufacturer guidance

Availability of lengths varies depending of chosen tapping

configuration and height.

Depth

49 mm.

Tapping configuration

Tapping code 72.

Guidance for specification option:

Tapping type: Top/bottom tappings flow right/left.

Sustainability data

Contains Red List materials

No

Country of material origin

Europe

Country of product manufacture

Europe

Recyclability

Can be recycled

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

95 %

BIM objects

Platform Compatible Version
Revit
-

1

Literature

Hudevad Niveau Vertical

Hudevad Niveau Vertical
