Hudevad Classic - Radiator
Verified by manufacturer 3 months ago
Type 11
Type 11
Sectional radiator.
Application
Suitable for the interior of any room. Can be used in commercial settings, private homes and office spaces.
Description
A Scandinavian, sectional radiator. The radiator is an aesthetic radiator with a classic look, for modern retro decor. Suitable for all kinds of modern buildings. Can be used as a wall mounted version or with integrated feet.
Features and benefits:
- Danish design.
- Can be adapted to all common connection types and dimensions.
- Available in four different types.
General information
Color | White Guidance for specification option: RAL 9016. Other |
Finish | Powder-coated |
Material | Steel |
Shape | Rectangle |
Length | 30 mm Guidance for specification option: Type 11 minimum. 45 mm Guidance for specification option: Type 22, 33 and 44 minimum. 4000 mm Guidance for specification option: Maximum. Manufacturer guidanceType 11: 30–4000 mm. Type 22, 33 and 44: 45–4000 mm. |
Width | 75 mm 125 mm 190 mm 280 mm |
Height | 300 mm 500 mm 590 mm 740 mm 990 mm |
Warranty description | Ten year |
Uniclass | |
CAWS | T90/465 Radiators T90/465 Radiators |
Specification data - Radiators
Standards | To BS EN 442-1 and BS EN 442-2. |
Radiator type | Single convector panel. |
Output | Guidance for specification option: Consult manufacturer and insert requirements. |
Finish | Powder-coated.Guidance for specification option: In accordance with DIN 55900, BS EN 442. |
Connections | 1/2” ABCD.Guidance for specification option: Air vent and plugs included. |
Accessories | Rule bracket.Integrated support feet.Adjustable support feet.Integrated valve system TA Tworett 2 pipes.Integrated valve system TA Tworett 1 pipe.Integrated valve system Danfross RAK-VB 2 pipes.Integrated valve system Danfross RA-KE 1 pipe.Danfoss RA-N valve.Not required. |
Heating element | To BS EN 10130/10131, cold-rolled steel plate. |
Colour | White RAL 9016. Guidance for specification option: Standard. Other. Guidance for specification option: Can be painted in other colours. Insert requirements. |
TestPressure | 8 bar. |
Operating pressure (maximum) | 6 bar. |
Operating temperature | 120°C. |
Height | 300 mm. Guidance for specification option:
500 mm. Guidance for specification option:
590 mm. Guidance for specification option:
740 mm. Guidance for specification option:
990 mm. Guidance for specification option:
Manufacturer guidanceConsult manufacturer's literature for details. |
Width | 30–4000 mm. Guidance for specification option: Consult manufacturer's literature and insert requirements. Manufacturer guidanceAvailability of width varies depending of chosen tapping configuration and height. |
Depth | 75 mm. |
Tapping configuration | Tapping code 10. Guidance for specification option: Tapping type: ABCD. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Europe |
Country of product manufacture | Sweden |
Recyclability | Can be recycled |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 95 % |
BIM objects
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
Literature
Classic
