NBS Source
I'm a manufacturer
Compare variants

Heated Lockers

Verified by manufacturer 19 days ago

One compartment

Helmsman Variant:

Heated lockers, manufactured from durable solid grade laminate and can come in all shapes and sizes including Z shaped locker.

Jump to:
BOS
+44 (0)1284 530427 Website

Application

Ideal for offices and industrial warehouses where employees may need storage and space to dry damp clothing.

Description

Heated lockers manufactured from aluminium and stainless steel with a Solid Grade Laminate door. Heat is generated from a single or twin eco-friendly tube heater. The heater can be plugged into a three-pin power socket or wired into a fused switch.


Features and benefits:

  • Can withstand heavy usage.
  • Durable and robust heated storage solution.
  • Suitable for offices and commercial facilities.
  • Supplied fully assembled; installation service available.
  • Lockers come with a 175 mm stand where the heater is concealed and perforations at the top of the locker to allow damp air to circulate.

General information

Color

-

Manufacturer guidance

Consult manufacturer and insert requirements.

Finish

Smooth

Powder-coated

Material

Aluminium

Guidance for specification option:

Body.

Stainless steel

Guidance for specification option:

Frame.

Laminate

Guidance for specification option:

10/12 mm solid grade laminate door.

Shape

Rectangle

Length

300 mm

380 mm

450 mm

Width

300 mm

380 mm

450 mm

Height

1775 mm

1800 mm

Warranty description

One year

Guidance for specification option:

Standard.

Manufacturer guidance

Other options available, consult with the manufacturer.

Uniclass

Pr_40_30_87_48 LockersPrimary

CAWS

N10/10 Purpose-made

N10/220 Lockers

Specification data - Lockers

Dimensions

1775 x 300 x 300 mm.

1775 x 300 x 450 mm.

1775 x 380 x 450 mm.

1775 x 450 x 450 mm.

1800 x 300 x 300 mm.

1800 x 300 x 450 mm.

1800 x 450 x 450 mm.

Bespoke.

Material

Aluminium and stainless steel.

Finish

Powder coated, smooth.

Guidance for specification option:

Stainless steel.

Colour

Guidance for specification option:

Consult manufacturer and insert requirements.

Fittings

Not required.

Coat rail and two hooks.

Guidance for specification option:

Fitted in locker compartment (one & two compartments only).

Thermostat

Not required.

Electric plug-in thermostat.

Guidance for specification option:

With 24-hour control. Programmable time periods within 4 operating modes including ON, OFF, timed and automatic. Set temperature between 0 to 35 degrees Celsius.

Lock

Camlock.

Guidance for specification option:

As standard.

Haps and stample.

Guidance for specification option:

As standard.

Coin return/retain.

Guidance for specification option:

Supplied on request.

Combination.

Guidance for specification option:

Supplied on request.

Digital.

Guidance for specification option:

Supplied on request.

Accessories

Not required.

Key wrist straps.

Key fobs.

Number plates.

Guidance for specification option:

Each door is supplied with a plastic oval number plate recessed into the door as standard. Maximum of four numbers per number plate. Optional extras for numbers to be engraved into the locker or to have Braille numbering.

End panels.

Guidance for specification option:

Solid Grade Laminate colours available, consult the manufacturer. All necessary fixings supplied.

Show more

Locker door numbering

Plastic oval number plate.

Guidance for specification option:

Recessed into the door, as standard.

Number engraved.

Guidance for specification option:

Options to be supplied with a number engraved into the door.

Stands/ seats

175 mm stand.

Guidance for specification option:

Lockers come with a stand where the heater is concealed.

Heater

Single ECO-friendly tube heater.

Twin ECO-friendly tube heater.

Facing

10 mm solid grade laminate.

Manufacturer guidance

Door facing.

Locking system

Cam locks.

Swivel locks.

Manufacturer guidance

Cam locks or swivel locks are standard locks (padlock not included). Other locking systems are available on request.

Hinges

Sprung.

Unsprung.

Hooks

Nylon.

Guidance for specification option:

Supplied with nylon hooks on each side of the compartment, only for one and two compartment lockers.

Sustainability data

Contains Red List materials

No

Country of product manufacture

United Kingdom
