Halo Rustique Tilt and Turn Window - PVC-U Window System

Verified by manufacturer 2 months ago

VEKA plc Third party certifications:
  • BSI Kitemark

    BSI Kitemark

    Certificate type

PVC-U Tilt and Turn window system

Jump to:
+44 (0)1282 716611 Website

Application

PVC-U tilt and turn windows that are suitable to fit a range of applications.

Description

Suitable for when the authentic look and feel of a traditional sculptured window is desired, but the functionality and performance of a modern PVC-U is demanded. With a distinctive two part opening mechanism to allow for either ventilation or full opening; the blend of aesthetics and technology combine to present an inward opening window solution available in a large assortment of colours and woodgrain options from VEKA plc's Variations range.


Features and benefits:

  • Tilt and turn configuration.
  • Large assortment of colours and woodgrain options.
  • Sculptured or bevelled options available.
  • Complies to BS EN 12608-1+A1:2020/ PAS 24:2022.

General information

Color

Beige

Black

Blue

Brown

Cream

Show more

Manufacturer guidance

Available in a large assortment of colours and woodgrain options from the Variations range.

Finish

Coated

Woodgrain

Material

PVC-U

Shape

Rectangle

Square

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

Ten year

Uniclass

Pr_30_59_98_92 Unplasticized polyvinyl chloride (PVC-U) window unitsPrimary

CAWS

L10/30 PVC-U windows

L10/350 PVC-U windows

Specification data - Unplasticized polyvinyl chloride (PVC-U) window units

Standard

Non-fire and/ or smoke-rated windows to BS EN 12608 and BS 7412.

Third-party certification

Third-party-accredited by BSI Kitemark™.

Dimensions and configurations

-

Manufacturer guidance

Consult manufacturer and insert requirements.

  • Maximum sash size (W x H): 1414 x 1414 mm.

Product performance

-

Weather performance

-

UK exposure category

To BS 6375-1, 1600 Pa.

Air permeability

To BS 6375-1, Class 4.

Watertightness

E1050.

Resistance to wind load

To BS 6375-1, Class A4.

Durability

-

Operation and strength characteristics

To BS 6375-2.

Safety

-

Security level

To PAS 24.

Thermal

-

Whole window U-value

1.2 W/m2K.

Guidance for specification option:

Achieves U-values as low as 1.2 W/m2K using double glazing.


0.99 W/m2K.

Guidance for specification option:

Achieves U-values as low as 0.99 W/m2K using triple glazing.

Frame

-

Profile

To BS EN 12608-1.

Colour and texture

-

Manufacturer guidance

Consult manufacturer and insert requirements.


Available in a large assortment of colours and woodgrain options from the Variations range.

Glazing or infill

-

Requirements

Double glazed.

Triple glazed.

Hardware

-

Manufacturer guidance

Consult manufacturer and insert requirements or omit.

Operation

-

Type

Manual.

Fixing features

Manufacturer's standard.

Outer frame

56 mm.

72 mm.

84 mm.

Mullions

70 mm.

95 mm.

Sash

Tilt and turn sash.

Glazing beads

24 mm sculptured.

28 mm sculptured.

32 mm sculptured.

36 mm bevelled.

40 mm bevelled.

Sustainability data

Country of product manufacture

United Kingdom

Material

PVC-U

Recyclability

Through our advanced recycling process, each PVCu frame can achieve a potential lifetime of 350 years. VEKA Recycling Ltd offer a fully circular solution for PVCu waste management. Collected and processed in the UK, for use in the UK.

Expected Life

35 year

Guidance for specification option:

Through our closed loop process, we can recycle windows and doors up to 10 times. This means each frame can achieve a potential lifetime of 350 years.

Manufacturer guidance

Through our closed loop process, we can recycle windows and doors up to 10 times. This means each frame can achieve a potential lifetime of 350 years.

Third party certifications

BSI Kitemark

BSI Kitemark

Halo Rustique Window Kitemark™ Certificate No. KM 33520

Literature

Halo Rustique Tilt and Turn Window Specification

Halo Rustique Tilt and Turn Window Specification
