Gatic LFA Assist Lift Covers
Verified by manufacturer 1 month ago
Gatic LFA 750
Gatic LFA 750
UKAS
Certificate type
Heavy Duty Lift Assist Lift Covers for rapid access in slow moving traffic locations.
Application
Suitable for ultra-heavy duty use in demanding areas subject to slow moving traffic such as:
- Aircraft pavements
- Taxiways of civil airports
- Dockyards
Sealed assist lift options are available. Consult manufacturer for information.
Description
Heavy duty lift assist lift covers for rapid access.
Features and benefits:
- Automatic engaging mechanism to prevent accidental closure.
- Slam latch included.
- Locking feature with a single Allen key for opening.
- Integrated lift handle.
- Provides safe lifting feature as covers have been designed to be lifted by a single user.
- Approximate operating weight is 25 kg.
- M-Struts® provide a maintenance free alternative to conventional gas struts as they contain no internal gases to leak or seals that can fail in extreme conditions.
- Can withstand the test load, deflection and maximum deformation criteria specified in BS EN 124 F900.
General information
Material | Iron Guidance for specification option: Ductile iron components to BS 1563:2011. Stainless steel Guidance for specification option: M-Struts® and other parts grade 1.4301 (304) stainless steel. |
Uniclass | |
CAWS | P31/370 Access covers/ gratings R12/471 Access covers and frames R13/640 Cast iron access covers and seating |
Product range |
Specification data - Access covers, gratings and frames
Configuration | Single. |
Load class (minimum) | F 900. |
Total weight | 25 kg (approximate operating weight). |
Dimensions | 750 x 750 mm. |
Sustainability data
Contains Red List materials | No |
Country of product manufacture | United Kingdom |
Material | Iron Guidance for specification option: Ductile iron components to BS 1563:2011. Stainless steel Guidance for specification option: M-Struts® and other parts grade 1.4301 (304) stainless steel. |
Third party certifications
UKAS
ISO 9001 - Dover Site
Literature
Gatic Access Covers
Gatic Ports and Airports
