Lightweight glass fibre reinforced concrete (GRC) panelised rainscreen system.
A lightweight concrete panel, reinforced with glass fibres that can be shaped and sized to suit the exact specification of any project.
It has the performance characteristics expected of reinforced concrete, yet each panel is just 15 mm thick. The Fibreform G panel is profiled with a 10 x 3 mm aluminium insert channel to facilitate easy installation onto two horizontal carrier rails (top and bottom) to reduce costs and the need for a specialist workforce.
It is available in a choice of standard and bespoke colours and finishes and is perfect for creating special column casings, cornicing, copings and other unique design solutions.
Features and benefits:
Random stretcher bond
|Carrier Rail System|
TI-G TI Tracking Generic Rail System, mill finish
TI-G TI Tracking Generic Rail System, powder coated black
Single crank, insert size.
|Standard product features|
±3600 pascals (Pa).
Cyclic wind loading:
±600–2400 pascals (Pa) over a 24 hour period.
Impact resistance (BS 8200):
Acoustic sound absorption:
40 dB at 4000 Hz.
Bespoke options available, consult manufacturer and insert requirements.
Carrier Rail System:
External corners, window, curtain walling head returns, soffits and window jambs dressed and filled, available with preformed returns at 100 mm standard.
