Evolve - Automated Sliding Door System

Name: Evolve - Automated Sliding Door System
Brand: P C Henderson Ltd
SKU: 7UZe4GXy4VKJayw3vM48Lu

Verified by manufacturer 13 days ago

E80/20 (single wood or metal door; 2 m track)

Automated sliding system for wooden, metal or glass doors weighing up to 80 kg.

Jump to:

Application

Automated sliding system for wooden, metal or glass doors weighing up to 80 kg (single door) or 40 kg (per leaf, bi-parting doors).
For internal use.
Suitable for mobility access or light commercial applications.

Automated sliding system for wooden, metal or glass doors weighing up to 80 kg.

Features and benefits:

Offers a smooth and reliable automated sliding system.
Suitable for single or bi-parting doors.
Maximum weight capacity 80 kg per door (single door) or 40 kg per door (bi-parting).
Available in kit pack format. The kit includes wall-mounted control panels to allow the doors to be opened by the push of a button.
Alternatively a remote control or motion sensor can be purchased as an optional extra.

Kit components:

Color	Silver
Shape	Rectangle
Length	2000 mm 3000 mm 4000 mm Guidance for specification option: 2 x 2000 mm tracks.
Width	Bespoke
Warranty description	Ten year

Uniclass	Pr_30_36_36_23 Door track and running gearPrimary
CAWS	P21/10 Door track and running gear P21/350 Door track and running gear

Standard	To BS EN 1527.
Classification grades (minimum)	-
Durability	Manufacturer's standard.
Door mass	2. Guidance for specification option: Up to 80 kg.
Corrosion resistance	Manufacturer's standard.
Category of door-opening action	1.
Initial friction	Manufacturer's standard.
Form	Manufacturer's standard.
Integral accessories	Hangers; floor guide; track stops; toothed belt; belt clamp; tensions wheel; face fixed brackets; motor (1.5 m cable length); 24 V transformer; wall-mounted control panels.

Accessories	None. Remote control kit E2/RCK. Radar motion sensor, black ER/B. Radar motion sensor, white ER/W. Radar motion sensor, aluminium ER/S.
Length	Track: 2000 mm.
Door leaf	Material: wood/ metal. Thickness: 30–50 mm. Width: 675–1100 mm. Maximum weight: 80 kg. Manufacturer guidance Supplied by others.
Drive unit	Operation voltage: 24 V safety - low voltage via external power unit. Running performance: soft start and stop. Safety function: includes obstacle detection in both directions. Configurable options: push-and-go; closing speed; auto-closing delay timer can all be configured to user preference.
Speed	Maximum operating speed by door weight: · Up to 80 kg: 200 mm/s maximum. · Up to 60 kg: 230 mm/s maximum. · Up to 40 kg: 260 mm/s maximum.
